1 Process Data Input 1 (MSB) PV1 LSW PV1 LSW
2 Process Data Input 1 (LSB)
3 Process Data Input 2 (MSB) PV1 MSW PV1 MSW
4 Process Data Input 2 (LSB)
5 Process Data Input 3 (MSB) Input 1 LSW Active SetPoint LSW
6 Process Data Input 3 (LSB)
7 Process Data Input 4 (MSB) Input 1 MSW Active SetPoint MSW
8 Process Data Input 4 (LSB)
9 Process Data Input 5 (MSB) Input 2 LSW Deviation SP-PV LSW
10 Process Data Input 5 (LSB)
11 Process Data Input 6 (MSB) Input 2 MSW Deviation SP-PV LSW
12 Process Data Input 6 (LSB)
13 Process Data Input 7 (MSB) Input 3 LSW Input 1 LSW
14 Process Data Input 7 (LSB)
15 Process Data Input 8 (MSB) Input 3 MSW Input 1 MSW
16 Process Data Input 8 (LSB)
17 Process Data Input 9 (MSB) Input 4 LSW Input 2 LSW
18 Process Data Input 9 (LSB)
19 Process Data Input 10 (MSB) Input 4 MSW Input 2 MSW
20 Process Data Input 10 (LSB)
21 Process Data Input 11 (MSB) Math function A LSW Input 3 LSW
22 Process Data Input 11 (LSB)
23 Process Data Input 12 (MSB) Math function A MSW Input 3 MSW
24 Process Data Input 12 (LSB)
25 Process Data Input 13 (MSB) Math function B LSW Input 4 LSW
26 Process Data Input 13 (LSB)
27 Process Data Input 14 (MSB) Math function B MSW Input 4 MSW
28 Process Data Input 14 (LSB)
29 Process Data Input 15 (MSB) Controller status Math function A LSW
30 Process Data Input 15 (LSB)
31 Process Data Input 16 (MSB) Alarm status Math function A MSW
32 Process Data Input 16 (LSB)
The “Process data” Input show the value of the variable selected via the PARAMETERISATION TELEGRAM
described above.
