4.5.6 PROCESS DATA OUTPUT
The “Process data” Output area lets the operator immediately write the value of some significant variables of the
instrument connected to the PROFIBUS node.
PROCESS DATA OUTPUT
BYTE
PARAMETER
2400
2500
1 Process Data Output 1 (MSB) Alarm Point 1 LSW Local Setpoint LSW
2 Process Data Output 1 (LSB)
3 Process Data Output 2 (MSB) Alarm Point 1 MSW Local Setpoint MSW
4 Process Data Output 2 (LSB)
5 Process Data Output 3 (MSB) Alarm Point 2 LSW Setpoint 1 LSW
6 Process Data Output 3 (LSB)
7 Process Data Output 4 (MSB) Alarm Point 2 MSW Setpoint 1 MSW
8 Process Data Output 4 (LSB)
9 Process Data Output 5 (MSB) Alarm Point 3 LSW Setpoint 2 LSW
10 Process Data Output 5 (LSB)
11 Process Data Output 6 (MSB) Alarm Point 3 MSW Setpoint 2 MSW
12 Process Data Output 6 (LSB)
13 Process Data Output 7 (MSB) Alarm Point 4 LSW Alarm Point 1 LSW
14 Process Data Output 7 (LSB)
15 Process Data Output 8 (MSB) Alarm Point 4 MSW Alarm Point 1 MSW
16 Process Data Output 8 (LSB)
17 Process Data Output 9 (MSB) Alarm Point 5 LSW Alarm Point 2 LSW
18 Process Data Output 9 (LSB)
19 Process Data Output 10 (MSB) Alarm Point 5 MSW Alarm Point 2 MSW
20 Process Data Output 10 (LSB)
21 Process Data Output 11 (MSB) Alarm Point 6 LSW Alarm Point 3 LSW
22 Process Data Output 11 (LSB)
23 Process Data Output 12 (MSB) Alarm Point 6 MSW Alarm Point 3 MSW
24 Process Data Output 12 (LSB)
25 Process Data Output 13 (MSB) Alarm Point 7 LSW Alarm Point 4 LSW
26 Process Data Output 13 (LSB)
27 Process Data Output 14 (MSB) Alarm Point 7 MSW Alarm Point 4 MSW
28 Process Data Output 14 (LSB)
29 Process Data Output 15 (MSB) Alarm Point 8 LSW Alarm Point 5 LSW
30 Process Data Output 15 (LSB)
31 Process Data Output 16 (MSB) Alarm Point 8 MSW Alarm Point 5 MSW
32 Process Data Output 16 (LSB)
The “Process data” Output show the value of the variable selected via the PARAMETERISATION TELEGRAM
described above.
