gefran 2400 Guide To Configuration And Network Installation

80018C_MSW_2400-2500-Profibus_1209_ENG
Page 25
Output parameters:
 Done (BOOL) :
In this parameter the function writes 1 when the operation has ended
 Error (BOOL) :
In this parameter the function writes 1 when an error took place during the writing operation.
 ErrorCode (INT):
In this parameter the function gives the error code found in case of error
 ErrorParamNr (INT):
In this parameter, in case of error, the function writes the ordinal number in the DB with the list of the parameter
addresses that caused the error.
Example of DB with the list of the parameter of a 2500 instrument and relative addresses (in the exampleDB109):
Address
Name
Type
Value
Comment
5 Pb.1 INT 1000 Proportional band of group 1
7 It.1 INT 40 Integral time of group 1
8 dt.1 INT 0 Derivative time of group 1
10 LoS.1 INT 0 Min limit scale of input 1 LSW
11 HiS.1 INT 3500 Max limit scale of input 1 LSW
12 AL.1 INT 100 Alarm threshold 1 LSW
13 AL.2 INT 200 Alarm threshold 2 LSW
16 Set.P INT 0 Local setpoint LSW
27 Hy.1 INT 0 Hysteresis alarm 1
30 Hy.2 INT -1 Hysteresis alarm 2
31 S.tu INT 0 Enabling selftuning, autotuning and softstart
42 Hi.P INT 1000 Max power limit
43 Lo.P INT 0 Min power limit
45 bAu INT 4 Select baud rate
46 Cod INT 1 Unit identification code
47 Par INT 0 Parity selection
49 Pro INT 0 Protection code
52 AL.3 INT 300 Alarm threshold 3 LSW
53 Hy.3 INT -1 Hysteresis alarm 3
54 At.3 INT 0 Alarm 3 type
55 AL.4 INT 400 Alarm threshold 4 LSW
56 Hy.4 INT -1 Hysteresis alarm 4
57 At.4 INT 0 Alarm 4 type
62 At.1 INT 0 Alarm 1 type
63 At.2 INT 0 Alarm 2 type
65 P.On.t INT 0 Power-on mode
66 TypC.1 INT 1 Type of analog output C1
67 L.r.t INT 0 Local/remote setpoint switching mode
68 MA.t INT 0 Manual/automatic switching mode
69 A.M.t INT 0 Automatic/manual switching mode
70 Ctr INT 0 Control type
133 but.1 INT 8 Function of PEAK key
134 but.2 INT 15 Function of CAL/RST key
135 but.3 INT 13 Function of M/A key
136 tyP.3 INT 1 Input 3 type
155 tyP.2 INT 0 Input 2 type
400 tyP.1 INT 14 Input 1 type
403 dPS.1 INT 0 Decimal point position for input 1 scale
