I3 • TECHNICAL DATA
Power supply
- Supply with class 2 device
-24VDC±25%2Amax.,powerstheentireGILOGIKIIsystem
- polarity inversion protection
Ethernet
-standardRJ45connection
-16positionrotaryswitchfornodeidentificationonnetworkconfiguration
-StandardIEEE802.3
Diagnostics
-powersupplyon(yellowPOWERled)
-moduleinrun/configuration(greenRUNled)
-moduleorsysteminalarm/notconfigurated(redFAILled)
-yellowLINKled:networkconnected
-greenDATAled:datatransfer
Mechanical data
Dimensions:92x90x25,4mm
Weigth:150g.
Fixing:snapsontoR-BUS(x)
Protectionlevel:IP20
aMbient conditions
Working Temperature:0...50°C
Storage Temperature:-20...70°C
Humidity:max.90%Rhnotcondensing
For UL:Maximumsurroundingairtemperature50°C
4 • CONNECTIONS
ThemoduleinstallsonR-BUS(x)inthefirstslotontheleftifthereisnoR-SW5module;
inthesecondslotifthereisanR-SW5module.
(*) with the 18 position bus, positions 1, 2 are reserved
totheR-ETH100andR-SW5modules.
(*)
4
80127C_MHW_R-ETH100_08-2011_ENG
GEFRAN spaviaSebina,74-25050Provagliod’Iseo(BS)
Tel.03098881-fax0309839063-Internet:http://www.gefran.com
YellowLEDPOWER
GreenLEDRUN
RedLEDFAIL
GreenLEDDATA
YellowLEDLINK
Ethernet (*)
Supply (**)
RJ45
0 = no active
1..F=nodo1..F(1..15)
24Vdc
±25%
Max2A
(*)Usestandardcategory6cableaccordingtoTIA/EIA-568A
(**)Useunipolarcablewith1-1.5mmcrosssectionDonotattachalug
Rotaryswitchtoselectthenode
