Spare Part ListSpare Part List
Spare Part ListSpare Part List
Spare Part List
Code Description
Legend
US = Specify US Version
EU = Specify EU Version
Optional AccessoriesOptional Accessories
Optional AccessoriesOptional Accessories
Optional Accessories
970418 Piano Triple Pedal (Dual Foot Switch + Damper)
130301 2mt Midi Cable
AccessoriesAccessories
AccessoriesAccessories
Accessories
970134 Piano Single Foot Switch
271343 Owner's Manual
130283 Mains Cable (US)
130274 Mains Cable (EU)
Top AssemblyTop Assembly
Top AssemblyTop Assembly
Top Assembly
660738 Top Panel Chassis
653536 "b-#" Dual Actuator
653534 "ON/OFF" Single Actuator
653533 "RESET" Single Actuator
653532 "SPLIT P." Single Actuator
653531 "< >" Dual Actuator
653530 "TOUCH" Single Actuator
653529 "LOCAL OFF" Single Actuator
653528 "PRESET" Single Actuator
653527 "STORE" Single Actuator
653526 "LOCK" Single Actuator
653525 "TO LEFT" Single Actuator
653524 "CONTR." Single Actuator
653523 "5-6-7-8" Quad Actuator
653522 "1-2-3-4" Quad Actuator
653521 "- +" Dual Actuator
653520 "REVERB-PRO EFX" Dual Actuator
653519 "PARAM2-SEND" Dual Actuator
653518 "DEPTH-PARAM1" Dual Actuator
653517 "TIME-SEND" Dual Actuator
653516 "DEPTH-DELAY" Dual Actuator
653515 "SOUNDS-MIDI" Dual Actuator
653513 "DEMO" Single Actuator
653512 "USER" Single Actuator
653511 "E-F-G-H" Quad Actuator
653510 "A-B-C-D" Quad Actuator
651927 Plexiglass Bargraph Screen
651648 Plexiglass Lcd Display Screen
347409 Dark Gray/Red Slider Knob
341024 Black Knob
340986 D=3.3mm H=9mm Spacer for Metal Panel
340984 Slider Antidust Cover
340982 Plexiglass Green Display Screen
340978 Slider Frame
340976 Plexiglass Red Display Screen
340973 Plexiglass Encoder Led Screen
340426 D=7.5 H=13 Plastic Ferrule for Pitch/Mod Group
340186 Adhesive Cable Fixing
340115 Adhesive Flat Cable Fixing
210020 1.5x12mm Adhesive Red Felt (specify mt)
210017 2x10mm Adhesive Black Felt (specify mt)
210016 1x10mm Adhesive Black Felt (specify mt)
120581 M3 Black Self-Locking Nut
Right Control AssemblyRight Control Assembly
Right Control AssemblyRight Control Assembly
Right Control Assembly
810698 Right Control Assembly
810689 * Right Controls Panel Board (Pcb#310683)
340971 ** Encoder Led Support
340091 ** 4mm Led Spacer
230569 ** FL5R200PNT EMI Coil For Signal
141101 ** 4 Contacts Vert Male Connector
140953 ** 6 Contacts P=2.54mm Female Vert Strip
140910 ** 14 Contacts Vert Male Connector
140529 ** Microswitch 12V 50mA 0.25mm
110262 ** Dial Encoder with 15 Snap H=20mm Alps
103032 ** 74HC165D SOIC 8bit P To S Shift Register
103028 ** 74HC4094M1R SOIC 8bit Shift/Latch Register
103017 ** 74HC4051DW SOIC 8ch Analog Multiplexer
103000 ** 74HC14D Soic Hex Inverter Schmitt Trigger
100963 ** BA6218 SIP Reversible-motor Driver
080760 ** SA05-11EWA Kingb. 7 Segments Red Display
080759 ** 2x5mm Rect Diffused Green Led
080758 ** 2x5mm Rect Diffused Red Led
080736 ** DC-10EWA Kingb. 10 Elements Red Led Bar
080723 ** 3mm 40deg High Eff Red Led
055048 ** 10K 1/16w 5% Smd Resistor 0603
055032 ** 470E 1/16w 5% Smd Resistor 0603
055028 ** 220E 1/16w 5% Smd Resistor 0603
055024 ** 100E 1/16w 5% Smd Resistor 0603
031007 ** 10u 16V 20% Smd Electrolytic Tantalium Capacitor
011260 ** 100n 16V 10% Cer. Cap. Smd CL2 X7R 0603
011224 ** 100p 16V 10% Cer. Cap. Smd CL2 X7R 0603
731042 * Motorized Pot Board (Pcb#310689)
140956 ** 40 Contacts P=2.54mm H=8.5mm Male Vert Strip
130063 ** AWG24 Red Cable
130061 ** AWG24 Black Cable
072001 ** 10KB 60mm Motor Slider Pot. Shaft H=7.1mm
120028 * M3x6tc Black Screw
Left Control AssemblyLeft Control Assembly
Left Control AssemblyLeft Control Assembly
Left Control Assembly
810697 Left Control Assembly
810688 * Left Controls Panel Board (Pcb#310682)
731049 ** 3 Digit Display Board (Pcb#310698)
103028 *** 74HC4094M1R SOIC 8bit Shift/Latch Register
080761 *** PSA05-12GWA Kingb. 16 Segments Green Display
055032 *** 470E 1/16w 5% Smd Resistor 0603
011060 *** 100n 50V 10% Cer. Cap. Smd CL2 Y5V 0805
340971 ** Encoder Led Support
340091 ** 4mm Led Spacer
230569 ** FL5R200PNT EMI Coil For Signal
141101 ** 4 Contacts Vert Male Connector
140953 ** 6 Contacts P=2.54mm Female Vert Strip
140935 ** 6 Contacts Hor Male Connector
140910 ** 14 Contacts Vert Male Connector
140874 ** Single In Line Vert Male Strip (specify contacts)
140529 ** Microswitch 12V 50mA 0.25mm
110262 ** Dial Encoder with 15 Snap H=20mm Alps
103032 ** 74HC165D SOIC 8bit P To S Shift Register
103028 ** 74HC4094M1R SOIC 8bit Shift/Latch Register
103017 ** 74HC4051DW SOIC 8ch Analog Multiplexer
103000 ** 74HC14D Soic Hex Inverter Schmitt Trigger
100963 ** BA6218 SIP Reversible-motor Driver
080764 ** 3mm High Eff Green Led
080760 ** SA05-11EWA Kingb. 7 Segments Red Display
080758 ** 2x5mm Rect Diffused Red Led
080723 ** 3mm 40deg High Eff Red Led
055048 ** 10K 1/16w 5% Smd Resistor 0603
055032 ** 470E 1/16w 5% Smd Resistor 0603
055028 ** 220E 1/16w 5% Smd Resistor 0603
055024 ** 100E 1/16w 5% Smd Resistor 0603
031007 ** 10u 16V 20% Smd Electrolytic Tantalium Capacitor
011260 ** 100n 16V 10% Cer. Cap. Smd CL2 X7R 0603
011224 ** 100p 16V 10% Cer. Cap. Smd CL2 X7R 0603
731042 * Motorized Pot Board (Pcb#310689)
140956 ** 40 Contacts P=2.54mm H=8.5mm Male Vert Strip
130063 ** AWG24 Red Cable
130061 ** AWG24 Black Cable
072001 ** 10KB 60mm Motor Slider Pot. Shaft H=7.1mm
731041 * Potentiometer Board (Pcb#310689)
140955 ** 40 Contacts P=2.54mm H=7mm Male Vert Strip
072002 ** 10KB 60mm Vertical Slim Slider Pot. Shaft H=10mm
340981 * Spacer for Potentiometer
120028 * M3x6tc Black Screw
120021 * M2x6tc Screw
Lower Controls Panel BoardLower Controls Panel Board
Lower Controls Panel BoardLower Controls Panel Board
Lower Controls Panel Board
810694 Lower Controls Panel Board (Pcb#310687)
340091 * 4mm Led Spacer
141100 * 2 Contacts Vert Male Connector
140910 * 14 Contacts Vert Male Connector
140874 * Single In Line Vert Male Strip (specify contacts)
140860 * 14 Contacts Vert Male Dual In Line Strip
140529 * Microswitch 12V 50mA 0.25mm
103032 * 74HC165D SOIC 8bit P To S Shift Register
103028 * 74HC4094M1R SOIC 8bit Shift/Latch Register
103009 * 74HC02D SOIC Quad 2-In Nor Gate
103007 * 74HC74D SOIC Dual Flip-Flop
103000 * 74HC14D Soic Hex Inverter Schmitt Trigger
091004 * BC807-25L TO236 Smd Pnp Transistor (9FB/G5B)
081000 * PMLL4148 Smd 100mA 75V Signal Diode
080764 * 3mm High Eff Green Led
080762 * WM-C1602N-1GLY Wintek 2x16 Characters Lcd Display
080723 * 3mm 40deg High Eff Red Led
055060 * 100K 1/16w 5% Smd Resistor 0603
055048 * 10K 1/16w 5% Smd Resistor 0603
055044 * 4K7 1/16w 5% Smd Resistor 0603
055040 * 2K2 1/16w 5% Smd Resistor 0603
055036 * 1K 1/16w 5% Smd Resistor 0603
055032 * 470E 1/16w 5% Smd Resistor 0603
055027 * 180E 1/16w 5% Smd Resistor 0603
055024 * 100E 1/16w 5% Smd Resistor 0603
053012 * 10E 1/8w 5% Smd Resistor 1206
031007 * 10u 16V 20% Smd Electrolytic Tantalium Capacitor
030721 * 1000u 25V 20% Vert Electrolytic Capacitor
030485 * 100u 25V 20% Vert Electrolytic Capacitor
011260 * 100n 16V 10% Cer. Cap. Smd CL2 X7R 0603
011236 * 1n 16V 10% Cer. Cap. Smd CL2 X7R 0603
011103 * 1u 16V 10% Cer. Cap. Smd CL2 XTR 1206
010595 * 100n 50V -20+80% Ceramic Cap. Multilayer
Wiring ConnectionWiring Connection
Wiring ConnectionWiring Connection
Wiring Connection
841289 Single 7.5cm AWG18 White Faston/Faston Wire
841288 2 Wires 12.5cm Faston/Crimp Terminal Cable
841287 20 Wires 55cm Latch Flat Cable
841286 14 Wires 90cm Latch Flat Cable
841285 10 Wires 115cm Latch Flat Cable
841121 20cm Yel/Grn Faston/Faston Wire
841096 4 Wires 7,5cm Flat Cable
841006 10cm Yel/Grn Faston/Faston AWG18 Wire
840616 20 Wires 25cm Latch Flat Cable
840600 16 Wires 85cm Latch Flat Cable
840564 14 Wires 10cm Latch Flat Cable
840560 14 Wires 20cm Latch Flat Cable
770921 Supply Cables Assembly
Keyboard AssemblyKeyboard Assembly
Keyboard AssemblyKeyboard Assembly
Keyboard Assembly
720641 TP30 Keyboard Assembly with Interface Board
841084 * 20 Wires 35cm Flat Cable
840838 * 20 Wires 15cm Flat Cable
840791 * 2 Wires 40cm Crimp Terminal Cable
761226 * Keyboard Interface Board (Pcb#310697)
141018 ** 20 Contacts Vert Female Connector
140918 ** 2 Contacts Hor Male Connector
140852 ** 20 Contacts Hor Male Connector Din41651
103015 ** 74HC164D SOIC 8bit S To P Shift Register
103000 ** 74HC14D Soic Hex Inverter Schmitt Trigger
091001 ** BC857B/C TO236 Smd Pnp Transistor (9BB/C-3F/G)
081000 ** PMLL4148 Smd 100mA 75V Signal Diode
055100 ** 100E X4 1/16w 5% Smd Resistor Array
055048 ** 10K 1/16w 5% Smd Resistor 0603
055040 ** 2K2 1/16w 5% Smd Resistor 0603
055024 ** 100E 1/16w 5% Smd Resistor 0603
031007 ** 10u 16V 20% Smd Electrolytic Tantalium Capacitor
011260 ** 100n 16V 10% Cer. Cap. Smd CL2 X7R 0603
011228 ** 220p 16V 10% Cer. Cap. Smd CL2 X7R 0603
011103 ** 1u 16V 10% Cer. Cap. Smd CL2 XTR 1206
731033 * After-Touch Connection Board (Pcb#315187)
140918 ** 2 Contacts Hor Male Connector
140890 ** 4 Contacts Hor Male Single-Strip
720640 * TP30 Keyboard Assembly (end to SN.142B020250)
720662 * TP30 Keyboard Assembly (start from SN.142D020497)
810552 ** 39N Left Contacts Board (Pcb#310531)
340764 *** 3 Dual Contacts Rubber Strip
340211 *** 12 Dual Contact Rubber Strip
141018 *** 20 Contacts Vert Female Connector
141010 *** 4 Contacts Vert Female Connector
080103 *** 1N4148 100mA 75V Signal Diode
810551 * 49N Right Contacts Board (Pcb#310530)
340212 ** 13 Dual Contact Rubber Strip
340211 *** 12 Dual Contact Rubber Strip
141018 *** 20 Contacts Vert Female Connector
141010 *** 4 Contacts Vert Female Connector
080103 *** 1N4148 100mA 75V Signal Diode
151272 ** First A Key (TP30)
151271 ** Sharp Key (TP30)
151270 ** B Key (TP30)
151269 ** A Key (TP30)
151268 ** G Key (TP30)
151267 ** F Key (TP30)
151266 ** E Key (TP30)
151265 ** D Key (TP30)
151264 ** C Key (TP30)
160221 ** Key Return Spring (TP30) (720662 only)
340092 * 5mm Board Spacer
120281 * WL3x15tt Black Screw
Cpu & Sound Generator BoardCpu & Sound Generator Board
Cpu & Sound Generator BoardCpu & Sound Generator Board
Cpu & Sound Generator Board
761257 Cpu & Sound Generator Board (Pcb#315171)
761228 * Cpu & Sound Generator Board (Pcb#315171) not supplied, refer to
761257.
141102 ** 6 Contacts Vert Male Connector
140957 ** 20 Contacts P=2mm Male Vert Strip
140950 ** 120 Contacts Female PCI Edge Connector
140910 ** 14 Contacts Vert Male Connector
140877 ** Jumper For Contacts Strip (p=2.54mm)
140874 ** Single In Line Vert Male Strip (specify contacts)
140872 ** 4 Contatcs Hor Male Connector
031007 * 10u 16V 20% Smd Electrolytic Tantalium Capacitor
011260 * 100n 16V 10% Cer. Cap. Smd CL2 X7R 0603
011224 * 100p 16V 10% Cer. Cap. Smd CL2 X7R 0603
011103 * 1u 16V 10% Cer. Cap. Smd CL2 XTR 1206
Pitch & Modulation AssemblyPitch & Modulation Assembly
Pitch & Modulation AssemblyPitch & Modulation Assembly
Pitch & Modulation Assembly
720644 Pitch & Modulation Assembly
770923 * Pitch & Modulation Cables Assembly
720647 * Fatar 41918180 Pitch & Modulation Kit (This part is replaced entirely only)
Bottom AssemblyBottom Assembly
Bottom AssemblyBottom Assembly
Bottom Assembly
653581 Lateral Block for Keyboard
262319 Wooden Right Side
262318 Wooden Left Side
180643 Phones Adhesive Plate
171838 Right Side Angular Support
171837 Left Side Angular Support
120581 M3 Black Self-Locking Nut
120374 WL4x15tt Black Screw
120147 M4x10tt Black Screw
120034 M4x12tc Black Screw
660751 Option Slot Closer
660740 Bottom Chassis
653514 Stand-By Actuator
340435 Adhesive Foot
340370 Contrast Knob
340186 Adhesive Cable Fixing
340115 Adhesive Flat Cable Fixing
340093 Board Spacer
210042 2x10mm Adhesive Spik (specify mt)
171887 Hinge
171866 Battery Support
171860 Slot Board Holder
150298 100x2.5mm Nylon Cable Tie
120825 6.2mm Spacer Screw
120581 M3 Black Self-Locking Nut
120483 5mm Black Shakeproof Washer
120120 M5x10tc Black Screw
120028 M3x6tc Black Screw
Supply AssemblySupply Assembly
Supply AssemblySupply Assembly
Supply Assembly
110614 Mains Socket
110285 4A 250Vac Bipolar Power Switch
731011 SNP9541M 40W Switching Supply Unit
Pot Motor Supply & Stand-by BoardPot Motor Supply & Stand-by Board
Pot Motor Supply & Stand-by BoardPot Motor Supply & Stand-by Board
Pot Motor Supply & Stand-by Board
110323 3.6V 1.3Ah NiMh Battery Pack with NTC
731050 Pot Motor Supply & Stand-by Board (Pcb#310678)
340079 * TO220 Mica Washer
340078 * TO220 Insulated Bush
171867 * TO220 h=38mm Heatsink
170960 * TO220 h=25mm Heatsink
141102 * 6 Contacts Vert Male Connector
140873 * 4 Contacts Vert Male Connector
140872 * 4 Contatcs Hor Male Connector
120581 * M3 Black Self-Locking Nut
120114 * M3x12tc Black Screw
106012 * LMC7221BIM5 SOT23-5 Cmos Comparator
106011 * LD2981 SOT23-5L 3.3V 0.1A Low Drop Regulator
106010 * MC33340D SO-8 Battery Fast Charge Controller
100066 * LM317T TO220 1.2-37V 1.5A Adjustable Regulator
091004 * BC807-25L TO236 Smd Pnp Transistor (9FB/G5B)
091003 * BC817-25L TO236 Smd Npn Transistor (8FB/G6B)
090558 * TIP127 TO220 Pnp Darlington Transistor
081000 * PMLL4148 Smd 100mA 75V Signal Diode
080752 * 3mm Wide Diffused Red Led
080171 * FE6B 6A 100V Fast Recovery Diode
080156 * 1N4002 1A 100V Rectifier Diode
060171 * 2E2 2W 10% Resistor
060087 * 0E47 5W 5% Wire Resistor
055072 * 1M 1/16w 5% Smd Resistor 0603
055068 * 470K 1/16w 5% Smd Resistor 0603
055064 * 220K 1/16w 5% Smd Resistor 0603
055057 * 56K 1/16w 5% Smd Resistor 0603
055056 * 47K 1/16w 5% Smd Resistor 0603
055048 * 10K 1/16w 5% Smd Resistor 0603
055045 * 5K6 1/16w 5% Smd Resistor 0603
055044 * 4K7 1/16w 5% Smd Resistor 0603
055040 * 2K2 1/16w 5% Smd Resistor 0603
055036 * 1K 1/16w 5% Smd Resistor 0603
055032 * 470E 1/16w 5% Smd Resistor 0603
055028 * 220E 1/16w 5% Smd Resistor 0603
050371 * 1K 1/4W 5% Resistor
040302 * 270E 1/2W 5% Resistor
040234 * 82E 1/2W 5% Resistor
To Next Page
Loading...
