011260 * 100n 16V 10% Cer. Cap. Smd CL2 X7R 0603
011103 * 1u 16V 10% Cer. Cap. Smd CL2 XTR 1206
In/Out BoardIn/Out Board
In/Out BoardIn/Out Board
In/Out Board
731043 In/Out Board (Pcb#310688)
230569 * FL5R200PNT EMI Coil For Signal
141102 * 6 Contacts Vert Male Connector
140944 * 10 Contacts Vert Male Connector Din41651
140854 * 16 Contacts Vert Male Connector Din41651
140851 * 20 Contacts Vert Male Connector Din41651
140247 * 8 Poles Mini Din Female Socket
140217 * Jack Stereo Slim Horizontal Socket
140212 * 5 Poles Din Horizontal Female Socket
140207 * Jack Horizontal F Socket (with dual switch)
110322 * 2sw 3pos Slide Switch
110305 * Relay 12V / 2 Switch 1A 250Vac
106007 * TDA8542AT SOIC 2X1.5W BTL Audio Amplifier
100919 * MC33078 Dual LN Operational Amplifier
100734 * MAX202E RS232 Drivers/Receiver
100602 * 74HC04 Hex Inverter
100600 * 74HC00 Quad 2-Input Nand Gate
100035 * 6N138 Optocoupler
090194 * BC560C TO92 LN Pnp Transistor
090152 * BC337 TO92 Npn Transistor
080156 * 1N4002 1A 100V Rectifier Diode
080103 * 1N4148 100mA 75V Signal Diode
070231 * 47K 20% Ver Linear Trimmer +Knob
052072 * 1M 1/8w 5% Resistor
052060 * 100K 1/8w 5% Resistor
052050 * 15K 1/8w 5% Resistor
052048 * 10K 1/8w 5% Resistor
052047 * 8K2 1/8w 5% Resistor
052044 * 4K7 1/8w 5% Resistor
052040 * 2K2 1/8w 5% Resistor
052030 * 330E 1/8w 5% Resistor
052028 * 220E 1/8w 5% Resistor
052020 * 47E 1/8w 5% Resistor
052006 * 3E3 1/8w 5% Resistor
043480 * 10K0 1/8w 1% Resistor
030565 * 220u 25V 20% Vert Electrolytic Capacitor
030403 * 47u 25V 20% Vert Electrolytic Capacitor
030245 * 10u 50V 20% Vert Electrolytic Capacitor
030170 * 4u7 50V 20% Vert Electrolytic Capacitor
021028 * 220n 63V 10% MKT Polyester Capacitor
010740 * 1MHz Ceramic Resonator
010595 * 100n 50V -20+80% Ceramic Cap. Multilayer
010462 * 1n 50V 10% CL2 Ceramic Capacitor
010345 * 100p 50V 10% CL2 Ceramic Capacitor
010271 * 22p 50V 10% CL2 Ceramic Capacitor
Phones/Stand-by BoardPhones/Stand-by Board
Phones/Stand-by BoardPhones/Stand-by Board
Phones/Stand-by Board
731045 * Phones/Stand-by Board (Pcb#310702)
340091 ** 4mm Led Spacer
230569 ** FL5R200PNT EMI Coil For Signal
140954 ** 10 Contacts Hor Male Connector Din41651
140890 ** 4 Contacts Hor Male Single-Strip
140529 ** Microswitch 12V 50mA 0.25mm
140217 ** Jack Stereo Slim Horizontal Socket
080742 ** 3mm Wide Diffused Red-Grn Led
050191 ** 33E 1/4W 5% Resistor
010595 ** 100n 50V -20+80% Ceramic Cap. Multilayer
140851 ** 20 Contacts Vert Male Connector Din41651
106009 ** LM1117DTX-ADJ Voltage Reg.0,8A TO252
106003 ** MAX709 Power Monitor With Reset
106001 ** MC33078P SOIC Dual Low Noise Op. Amp.
105019 ** GVS99372 DRAKE (White Dot)
104065 ** IS41LV16100/S50T 16Mbitx16 Edo Dram
104064 ** K9F2808U0M-YCB0 128Mbitx8 Nand Flash-mem
104052 ** AT24C64 64Kbit Serial Access EEProm
103507 ** 74HCT374 SOIC Octal D-Type Flip-Flop
103505 ** 74HCT138 SOIC 1 Of 8 Decoder
103502 ** 74HCT32 SOIC Quad 2-In Or Gate
103501 ** 74HCT04 SOIC Hex Inverter
103055 ** DS90LV018ATM SOIC Lvds Dif.line Receiver
103054 ** DS90LV017ATM SOIC Lvds Dif.line Driver
103053 ** AD1870 Single-supply 16bit Stereo Adc
103052 ** AD1854 Stereo 24bit Dac
103051 ** 74LVC374 SOIC Octal 3-state D Flip-flop
103050 ** 74LVC139 SOIC Dual 2 To 4 Line Decoder
103049 ** 74LVC74 SOIC Dual D Flip-flop
103048 ** 74LVC32D SOIC Quad 2-input Or Gate
103047 ** 74LVC04 SOIC Hex Inverter
103046 ** 74LVC125AD SOIC Quad Buffer/line Driver
103017 ** 74HC4051DW SOIC 8ch Analog Multiplexer
103012 ** 74HC125D SOIC Quad Tri-State Buffer
081000 ** PMLL4148 Smd 100mA 75V Signal Diode
070160 ** 2K2 20% Horizontal Linear Trimmer
055576 ** 1K5 1/16w 1% Smd Resistor 0603
055572 ** 1K0 1/16w 1% Smd Resistor 0603
055570 ** 820E 1/16w 1% Smd Resistor 0603
055562 ** 390E 1/16w 1% Smd Resistor 0603
055552 ** 150E 1/16w 1% Smd Resistor 0603
055105 ** 10E X4 1/16w 5% Smd Resistor Array
055102 ** 33E X4 1/16w 5% Smd Resistor Array
055101 ** 4K7 X4 1/16w 5% Smd Resistor Array
055099 ** 0E 1/16w 5% Smd Resistor 0603
055072 ** 1M 1/16w 5% Smd Resistor 0603
055060 ** 100K 1/16w 5% Smd Resistor 0603
055044 ** 4K7 1/16w 5% Smd Resistor 0603
055032 ** 470E 1/16w 5% Smd Resistor 0603
055028 ** 220E 1/16w 5% Smd Resistor 0603
055024 ** 100E 1/16w 5% Smd Resistor 0603
055018 ** 33E 1/16w 5% Smd Resistor 0603
055012 ** 10E 1/16w 5% Smd Resistor 0603
031007 ** 10u 16V 20% Smd Electrolytic Tantalium Capacitor
030485 ** 100u 25V 20% Vert Electrolytic Capacitor
011260 ** 100n 16V 10% Cer. Cap. Smd CL2 X7R 0603
011248 ** 10n 16V 10% Cer. Cap. Smd CL2 X7R 0603
011238 ** 1n5 16V 10% Cer. Cap. Smd CL2 X7R 0603
011236 ** 1n 16V 10% Cer. Cap. Smd CL2 X7R 0603
011232 ** 470p 16V 10% Cer. Cap. Smd CL2 X7R 0603
011103 ** 1u 16V 10% Cer. Cap. Smd CL2 XTR 1206
010741 ** 11.2896MHz Quartz
761235 * 128Mbit Flash Memory Expansion Board (Pcb#310693)
142000 ** 20 Contacts P=2mm SMD Female Vert Strip
104064 ** K9F2808U0M-YCB0 128Mbitx8 Nand Flash-mem
031007 ** 10u 16V 20% Smd Electrolytic Tantalium Capacitor
011260 ** 100n 16V 10% Cer. Cap. Smd CL2 X7R 0603
Dual Drake Sound BoardDual Drake Sound Board
Dual Drake Sound BoardDual Drake Sound Board
Dual Drake Sound Board
761229 256+256Mbit Dual Drake Sound Board (Pcb#315179)
560023 * EPM3064ALC 44-4 EE Fpga "DRAKE PM3 PRG"
106009 * LM1117DTX-ADJ Voltage Reg.0,8A TO252
105020 * GVS99372 DRAKE (Red Dot)
104066 * K4S281632C-TC1L 128Mbitx16 Sync Dram 100MHz
104065 * IS41LV16100/S50T 16Mbitx16 Edo Dram
103056 * 74LVC245DW SOIC Octal Bus Transceiver
103055 * DS90LV018ATM SOIC Lvds Dif.line Receiver
103046 * 74LVC125AD SOIC Quad Buffer/line Driver
091004 * BC807-25L TO236 Smd Pnp Transistor (9FB/G5B)
091000 * BC847B/C TO236 Smd Npn Transistor (8BB/C-1F/G)
081100 * PRLL5817 SOD87 1A 20V Schottky Rect. Diode
055570 * 820E 1/16w 1% Smd Resistor 0603
055562 * 390E 1/16w 1% Smd Resistor 0603
055552 * 150E 1/16w 1% Smd Resistor 0603
055105 * 10E X4 1/16w 5% Smd Resistor Array
055102 * 33E X4 1/16w 5% Smd Resistor Array
055101 * 4K7 X4 1/16w 5% Smd Resistor Array
055099 * 0E 1/16w 5% Smd Resistor 0603
055044 * 4K7 1/16w 5% Smd Resistor 0603
055036 * 1K 1/16w 5% Smd Resistor 0603
055030 * 330E 1/16w 5% Smd Resistor 0603
055020 * 47E 1/16w 5% Smd Resistor 0603
055018 * 33E 1/16w 5% Smd Resistor 0603
055012 * 10E 1/16w 5% Smd Resistor 0603
031007 * 10u 16V 20% Smd Electrolytic Tantalium Capacitor
Note:Note:
Note:Note:
Note:
• All dimensions are in mm unless otherwise specified.
• The screw description is defined as follows:
type of screw + diameter + X + length + type of head
where type of screw is one of these:
M = Metric thread
B = Self-tapping screw for metal
WL = Self-tapping screw for wood
and type of head is one of these:
tc = cylinder Phillips head
ts = flared Phillips head
tt = rounded Phillips head
te = hexagonal nut head
tsp = flat flared Phillips head
tce = cylinder Allen hexagonal head
• The washer description is defined as follow:
hole diameter + X + external diameter + X + thick
• Each spare part is single quantity unless otherwise specified.
• Asterisk prefix explanation:
Omitted = First level spare part.
(*) One asterisk = Second level, part of previous listed first level part.
(**) Two asterisk = Third level, part of previous listed second level part.
(***) Three asterisk = ............
• Any request for not above mentioned part must encompass specific description
including:
1) Model name,
2) Section name,
3) Module code,
4) Reference name,
5) Quantity number.
