❏ 8
Spare Part List
Legend
EU = Specify European Version (230Vac)
US = Specify United States Version (115Vac)
WK1 = WK1 version only
WK1-Oriental = WK1-Oriental version only
Code Description
Optional Accessories
130301 2mt Midi Cable
970398 Video Interface (PAL Version)
970401 Video Interface (NTSC Version)
271342 * Video Board Installation Instructions
130317 * DIN/SCART Video Cable (Pal)(EU)
130428 * DIN/RCA Video Cable (Ntsc)(US)
120028 * M3x6tc Black Screw
Accessories
MDL345032 Music Stand
955881 WK1 Demo Disk
955880 WK1 Operating System Disk
271340 Owner's Manual (Italian-English-French-German)
271354 Owner's Manual (English-Arabian)
970315 230Vac/12Vdc Adapter 2.2A (EU)
970316 115Vac/12Vdc Adapter 2.2A (US)
Note: Spare part available entirely only.
Cabinet Assembly
MDL665003 Left Speaker Grid
MDL665002 Right Speaker Grid
MDL655069 <+100> Circular Actuator (WK1)
MDL655089 <+100> Circular Actuator (WK1-Oriental)
MDL655068 <+> Circular Actuator (WK1)
MDL655088 <+> Circular Actuator (WK1-Oriental)
MDL655067 <-> Circular Actuator (WK1)
MDL655087 <-> Circular Actuator (WK1-Oriental)
MDL655066 <0> Circular Actuator (WK1)
MDL655086 <0> Circular Actuator (WK1-Oriental)
MDL655065 <9> Circular Actuator (WK1)
MDL655085 <9> Circular Actuator (WK1-Oriental)
MDL655064 <8> Circular Actuator (WK1)
MDL655084 <8> Circular Actuator (WK1-Oriental)
MDL655063 <7> Circular Actuator (WK1)
MDL655083 <7> Circular Actuator (WK1-Oriental)
MDL655062 <6> Circular Actuator (WK1)
MDL655082 <6> Circular Actuator (WK1-Oriental)
MDL655061 <5> Circular Actuator (WK1)
MDL655081 <5> Circular Actuator (WK1-Oriental)
MDL655060 <4> Circular Actuator (WK1)
MDL655080 <4> Circular Actuator (WK1-Oriental)
MDL655059 <3> Circular Actuator (WK1)
MDL655079 <3> Circular Actuator (WK1-Oriental)
MDL655058 <2> Circular Actuator (WK1)
MDL655078 <2> Circular Actuator (WK1-Oriental)
MDL655057 <1> Circular Actuator (WK1)
MDL655077 <1> Circular Actuator (WK1-Oriental)
MDL655056 <Lower> Triangular Actuator (WK1)
MDL655076 <Lower> Triangular Actuator (WK1-Oriental)
MDL655055 <Upper 2> Triangular Actuator (WK1)
MDL655075 <Upper 2> Triangular Actuator (WK1-Oriental)
MDL655054 <Upper 1> Triangular Actuator (WK1)
MDL655074 <Upper 1> Triangular Actuator (WK1-Oriental)
MDL655053 <Cursor> Triangular Actuator (WK1)
MDL655073 <Cursor> Triangular Actuator (WK1-Oriental)
MDL655052
<Page <>
Triangular
Actuator (WK1)
MDL655072
<Page <>
Triangular Actuator
(WK1-Oriental)
MDL655051
<Page >>
Triangular
Actuator (WK1)
MDL655071
<Page >>
Triangular Actuator
(WK1-Oriental)
MDL655050 Lcd Display Screen
MDL655048 Controls Panel Chassis (WK1)
MDL655049 Controls Panel Chassis (WK1-Oriental)
MDL655047 Bottom Chassis
MDL655046 Top Chassis (WK1)
MDL655070 Top Chassis (WK1-Oriental)
MDL345046 <Start/Stop> Quadruple Actuator (WK1)
MDL345045 Double Circular Black Actuator (WK1)
MDL345054 Double Circular Black Actuator (WK1-Oriental)
MDL345044 16mm Circular Yellow Actuator (WK1)
MDL345053 16mm Circular Black Actuator (WK1-Oriental)
MDL345043 11mm Circular Green Actuator
MDL345042 11mm Circular Blue Actuator (WK1)
MDL345052 11mm Circular Gray Actuator (WK1-Oriental)
MDL345041 Trapezoidal Black Actuator
MDL345040 15x8mm Rectangular Green Actuator
MDL345039 15x8mm Rectangular Red Actuator
MDL345038 15x8mm Rectangular Gray Actuator
MDL345037 14x7mm Rectangular Gray Actuator
MDL345050 14x7mm Rectangular Red Actuator (WK1-Oriental)
MDL345049 14x7mm Rectangular Black Actuator (WK1-Oriental)
MDL345048 7mm Circular Black Actuator (WK1-Oriental)
MDL345047 7mm Circular Gray Actuator (WK1-Oriental)
MDL345036 Gray Power Switch Actuator (WK1)
MDL345020 Black Power Switch Actuator (WK1-Oriental)
MDL345035 Gray Volume Knob (WK1)
MDL345051 Black Volume Knob (WK1-Oriental)
MDL345034 Adhesive Rubber Foot
MDL345033 Battery Slot Cover
MDL345002 Rubber Contact Strip (step=20mm)
MDL345001 Rubber Contact Strip (step=14mm)
MDL345000 Single Rubber Contact for Controls
MDL225003 2" Tweeter Speaker
MDL225002 4" Woofer Speaker (WK1)
MDL225004 4" Woofer Speaker (WK1-Oriental)
MDL115000 On/Off Power Switch
347047 15.9mm Board Spacer
030202 4u7 25V 20% Vert Elect. Bipolar Capacitor
110400 3,5" Floppy Disk Drive
Controls Panel Assembly
MDL815011 Controls Panel Board (Pcb#31-1531-2) (WK1)
MDL815012 Controls Panel Board (WK1-Oriental)
MDL145034 * 4 Contacts Vert Male Connector
MDL145033 * 3 Contacts Vert Male Connector
140851 * 20 Contacts Vert Male Connector Din41651
080705 * 3mm 60deg Diffused Red Led
080103 * 1N4148 100mA 75V Signal Diode
MDL775000 Wiring Connections Kit
Note: Spare part available entirely only.
MDL735023 Volume Board
Note: Spare part available entirely only.
MDL735022 Modulation Board (Pcb#31-2002-0)
Note: Spare part available entirely only.
MDL735021 DC/AC Converter Board (Pcb#31-2000-1)
Note: Spare part available entirely only.
MDL735020 Lcd Display Board (Pcb#31-1527-1)
Note: Spare part available entirely only.
MDL735003 Pitch Wheel Assembly
Note: Spare part available entirely only.
Keyboard Assembly
MDL725002 61N Dynamic Keyboard Assembly
MDL815010 * Left Contacts Board (31Notes)
100606 ** 74HC138 1 Of 8 Decoder
080103 ** 1N4148 100mA 75V Signal Diode
030245 ** 10u 50V 20% Vert Electrolytic Capacitor
010590 ** 47n 50V -20+80% Ceramic Cap. Antispikes
010426 ** 470p 50V 10% CL2 Ceramic Capacitor
MDL815009 * Right Contacts Board (30Notes)
100606 ** 74HC138 1 Of 8 Decoder
080103 ** 1N4148 100mA 75V Signal Diode
010590 ** 47n 50V -20+80% Ceramic Cap. Antispikes
010426 ** 470p 50V 10% CL2 Ceramic Capacitor
Mdl345009 * 1 Octave Sharp Keys
MDL345008 * D-F-A Natural Keys
MDL345007 * C-E-G-B Natural Keys
MDL345006 * 13 Contacts Grey Strip
MDL345005 * 13 Contacts White Strip
MDL345004 * Last C Key
Cpu & Sound Generator Board
761233 Cpu & Sound Generator Board (Pcb#310681/1)(WK1)
761242 Cpu & Sound Generator Board (Pcb#310681/1)(WK1-Oriental)
MDL145045 * 15 Contacts Vert Male Connector
MDL145039 * 9 Contacts Vert Male Connector
MDL145034 * 4 Contacts Vert Male Connector
140910 * 14 Contacts Vert Male Connector
140889 * Dual In Line Vert Male Strip (specify contacts)
140877 * Jumper For Contacts Strip (p=2.54mm)
140866 * 34 Contacts Vert Male Connector Din41651
140854 * 16 Contacts Vert Male Connector Din41651
140851 * 20 Contacts Vert Male Connector Din41651
106001 * MC33078P SOIC Dual Low Noise Op. Amp.
105011 * IKE plus - Cpu & Dsp
104062 * KM68400ALG SOP 4Mbit 55ns Static Ram
104061 * K3N6C1000E-12 32Mbit Rom (WK1)
104063 * K3N6C1000E-12 32Mbit Rom (WK1-Oriental)
104032 * MX23C3210MC-12 32Mbit Rom "GM-GMX Sounds"
104026 * AM29F040-75EC TSOP 4Mbit Flash Memory Ta=70nS
103029 * 74HC4024D SOIC 7-Stage Binary Counter
103018 * 74HC126D SOIC Quad 3-State Buffer
103017 * 74HC4051DW SOIC 8ch Analog Multiplexer
103013 * 74HC138D SOIC 1 Of 8 Decoder
103010 * 74HC04D SOIC Hex Inverter
103008 * PCM69AU SOIC 2ch 1bit Dac
103003 * 74HC374DW SOIC Octal D-Type Flip-Flop
103002 * 74HC245DW SOIC Octal Bus Transceiver
103000 * 74HC14D Soic Hex Inverter Schmitt Trigger
100591 * GM82C765B Floppy Disk Controller
091002 * PMBT2369 TO236 Smd Npn Transistor
091001 * BC857 TO236 Smd Pnp Transistor
091000 * BC847 TO236 Smd Npn Transistor
081000 * PMLL4148 Smd 100mA 75V Signal Diode
055104 * 2K2 X4 1/16w 5% Smd Resistor Array
055103 * 470E X4 1/16w 5% Smd Resistor Array
055102 * 33E X4 1/16w 5% Smd Resistor Array
055101 * 4K7 X4 1/16w 5% Smd Resistor Array
055100 * 100E X4 1/16w 5% Smd Resistor Array
054072 * 1M 1/10w 5% Smd Resistor 0805
054068 * 470K 1/10w 5% Smd Resistor 0805
054052 * 22K 1/10w 5% Smd Resistor 0805
054050 * 15K 1/10w 5% Smd Resistor 0805
054048 * 10K 1/10w 5% Smd Resistor 0805
054046 * 6K8 1/10w 5% Smd Resistor 0805
054044 * 4K7 1/10w 5% Smd Resistor 0805
054042 * 3K3 1/10w 5% Smd Resistor 0805
054040 * 2K2 1/10w 5% Smd Resistor 0805
054038 * 1K5 1/10w 5% Smd Resistor 0805
054037 * 1K2 1/10w 5% Smd Resistor 0805
054036 * 1K 1/10w 5% Smd Resistor 0805
054034 * 680E 1/10w 5% Smd Resistor 0805
054028 * 220E 1/10w 5% Smd Resistor 0805
054024 * 100E 1/10w 5% Smd Resistor 0805
054018 * 33E 1/10w 5% Smd Resistor 0805
050131 * 10E 1/4W 5% Resistor
030565 * 220u 25V 20% Vert Electrolytic Capacitor
030485 * 100u 25V 20% Vert Electrolytic Capacitor
030403 * 47u 25V 20% Vert Electrolytic Capacitor
030245 * 10u 50V 20% Vert Electrolytic Capacitor
011502 * 470pFx4 10% 100V Cer. Array Cap. NP0 Smd
011501 * 220pFx4 10% 100V Cer. Array Cap. NP0 Smd
011500 * 47pFx4 10% 100V Cer. Array Cap. NP0 Smd
011064 * 220n 50V 10% Cer. Cap. Smd CL2 X7R 1206
011060 * 100n 50V 10% Cer. Cap. Smd CL2 Y5V 0805
011056 * 47n 50V 10% Cer. Cap. Smd CL2 X7R 0805
011048 * 10n 50V 10% Cer. Cap. Smd CL2 X7R 0805
011036 * 1n 50V 10% Cer. Cap. Smd CL2 X7R 0805
011032 * 470p 50V 10% Cer. Cap. Smd CL2 X7R 0805
011028 * 220p 50V 10% Cer. Cap. Smd CL2 X7R 0805
011024 * 100p 50V 10% Cer. Cap. Smd CL2 X7R 0805
011020 * 47p 50V 10% Cer. Cap. Smd CL2 X7R 0805
011018 * 33p 50V 10% Cer. Cap. Smd CL2 X7R 0805
011016 * 22p 50V 10% Cer. Cap. Smd CL2 X7R 0805
011012 * 10p 50V 10% Cer. Cap. Smd CL2 X7R 0805
010714 * 30MHz Quartz Resonator
010704 * 16MHz Quartz Resonator
Power Amplifier & Supply Board
731048 Power Amplifier & Supply Board (Pcb#310680)
MDL175001 * LM2576 Heatsink
MDL175000 * AN7148 Heatsink
MDL145034 * 4 Contacts Vert Male Connector
MDL145033 * 3 Contacts Vert Male Connector
MDL145032 * 2 Contacts Vert Male Connector
MDL100000 * AN7148 Dual Power Amplifier
MDL090000 * 9014C Npn TO92 Ebc 50V 0,15A
841283 * 9 Wires 7.5cm Solder/Crimp Terminal Cable
841282 * 4 Wires 7.5cm Solder/Crimp Terminal Cable
230569 * FL5R200PNT EMI Coil For Signal
230559 * 20uH 50V 3A Dc Line Filter
230527 * BL02RN2-R62 EMI Coil For Signal
230524 * 100uH Switching Coil
160178 * Copper Jumper
150298 * 100x2.5mm Nylon Cable Tie
140247 * 8 Poles Mini Din Female Socket
140217 * Jack Stereo Slim Horizontal Socket
140212 * 5 Poles Din Horizontal Female Socket
140211 * Dc Horizontal Male Socket
140207 * Jack Horizontal F Socket (with dual switch)
120276 * B2.9x6.5mm Screw
110282 * 3.6V 60mAh Nicd Battery
100955 * LM2576 5V 3A Switching Regulator
100734 * MAX202E RS232 Drivers/Receiver
100602 * 74HC04 Hex Inverter
100059 * 7805 +5V 1A Voltage Regulator
100035 * 6N138 Optocoupler
090856 * J176 TO92 P-Channel J-Fet Transistor
080170 * BYV27 2A 100V Fast Recovery Diode
080167 * 1N5403 3A 300V Rectifier Diode
080103 * 1N4148 100mA 75V Signal Diode
052060 * 100K 1/8w 5% Resistor
052056 * 47K 1/8w 5% Resistor
052053 * 27K 1/8w 5% Resistor
052052 * 22K 1/8w 5% Resistor
052049 * 12K 1/8w 5% Resistor
052048 * 10K 1/8w 5% Resistor
052046 * 6K8 1/8w 5% Resistor
052045 * 5K6 1/8w 5% Resistor
052044 * 4K7 1/8w 5% Resistor
052040 * 2K2 1/8w 5% Resistor
052036 * 1K 1/8w 5% Resistor
052032 * 470E 1/8w 5% Resistor
052028 * 220E 1/8w 5% Resistor
052024 * 100E 1/8w 5% Resistor
050551 * 33K 1/4W 5% Resistor
050211 * 47E 1/4W 5% Resistor
050054 * 2E2 1/4W 5% Resistor
030950 * 470u 16V 20% Low Esr Vert Electrolytic Capacitor
030805 * 2200u 25V 20% Vert Electrolytic Capacitor
030650 * 470u 25V 20% Vert Electrolytic Capacitor
030485 * 100u 25V 20% Vert Electrolytic Capacitor
030403 * 47u 25V 20% Vert Electrolytic Capacitor
030170 * 4u7 50V 20% Vert Electrolytic Capacitor
030005 * 1u 50V 20% Vert Electrolytic Capacitor
021030 * 330n 63V 10% MKT Polyester Capacitor
021024 * 100n 63V 10% MKT Polyester Capacitor
021016 * 22n 63V 10% MKT Polyester Capacitor
021004 * 2n2 63V 10% MKT Polyester Capacitor
010599 * 1u 50V -20+80% Ceramic Cap. Multilayer
010595 * 100n 50V -20+80% Ceramic Cap. Multilayer
010590 * 47n 50V -20+80% Ceramic Cap. Antispikes
Video Board (Optional Accessory)
761232 Video Board (Pcb#310679/1)
841281 * 14 Wires 10cm Latch/Transition Flat Cable
230582 * LC Delay Line 400ns 0.5MHz
140248 * 4 Poles Mini Din Female Socket
140219 * 13 Poles Din Horizontal Female Socket
106002 * NE555 SOIC Timer
106000 * TDA8501 PAL/NTSC Encoder
103019 * PCA8515 SOIC Standalone OSD
103012 * 74HC125D SOIC Quad Tri-State Buffer
103009 * 74HC02D SOIC Quad 2-In Nor Gate
103001 * 74HC08D SOIC Quad 2-Input And Gate
091000 * BC847 TO236 Smd Npn Transistor
081000 * PMLL4148 Smd 100mA 75V Signal Diode
055100 * 100E X4 1/16w 5% Smd Resistor Array
030931 * 10u 35V 20% Electrolytic Tantalium Capacitor
030565 * 220u 25V 20% Vert Electrolytic Capacitor
030403 * 47u 25V 20% Vert Electrolytic Capacitor
011064 * 220n 50V 10% Cer. Cap. Smd CL2 X7R 1206
011060 * 100n 50V 10% Cer. Cap. Smd CL2 Y5V 0805
011048 * 10n 50V 10% Cer. Cap. Smd CL2 X7R 0805
011047 * 8n2 50V 10% Cer. Cap. Smd CL2 X7R 0805
011036 * 1n 50V 10% Cer. Cap. Smd CL2 X7R 0805
011028 * 220p 50V 10% Cer. Cap. Smd CL2 X7R 0805
011016 * 22p 50V 10% Cer. Cap. Smd CL2 X7R 0805
010730 * 4.433619MHz Quartz Resonator
010729 * 3.579545MHz Quartz Resonator
010721 * 1.8432MHz Quartz Resonator
010602 * 5p2-30pF N750 Ceramic Capacitor Trimmer
010599 * 1u 50V -20+80% Ceramic Cap. Multilayer
Note:
Each spare part is single quantity unless otherwise specified.
All dimensions are in mm unless otherwise specified.
Asterisk prefix explanation:
Omitted = First level spare part.
One asterisk = Second level, part of previous listed first level part.
Two asterisk = Third level, part of previous listed second level part.
Three asterisk = ............
Any request for not above mentioned part must encompass specific description including:
1) Model name,
2) Section name,
3) Module code,
4) Reference name,
5) Quantity number.
To Previous Page
Loading...
General
