Gemas GSC10 User Manual

GEMAŞ Genel Mühendislik Mekanik San.veTic.A.Ş.
İTOB Organize Sanayi Bölgesi 10001 Sok.No:28 Menderes/İZMİR TURKEY
Tel:0232 799 0 333 Fax:0232 799 0 330 www.gemas.com.tr info@gemas.com.tr
4
EN GEMAŞ PURITRON GSC Installation and User Manual V4.1
1.PRODUCT FEATURES
• Produces chlorine in water with the same salt concentration as in tears.
• It has a user-friendly interface that provides ease of use with an LCD screen.
• It has an automatic electrode cleaning feature against calcification.
• It has a long-life titanium electrode.
• Has an electrode life of 16,000 hours.
• Provides the opportunity to adjust to the optimum level by increasing or decreasing the polarity change
time for cleaning the electrodes.
• Thanks to the Boost operating mode on the device, the instant chlorine need of the pool is provided.
• The pool cover has a closing control input.
• Thanks to the LCD screen, it provides the opportunity to monitor the current during operation.
• The device records the total working time.
• It can be easily applied to the existing pool.
• The recommended minimum salinity is 4000ppm (4kg / m3).
• The device can be used in seawater which is 35000ppm.
1.1.Technical Specifications
GSC10
064250
GSC20
064260
GSC30
064270
Chlorine Production
10gr/hour
20gr/ hour
30gr/ hour
Supply Voltage
220V AC
Electrode Current
Max. 2A
Max. 4A
Max. 6A
Electrode Voltage
Max. 24V
Power consumption
50W
100W
150W
Max. Pool
Dimensions
Temperate
50m³
100m³
170m³
Tropical
35m³
65m³
110m³
Maximum Flow
450 l/min
Maximum Pressure
320 Kpa
Pressure drop
5 Kpa
Cell Type
Bipolar
Salt Concentration
4-35gr/l
Cell Material
PMMA
Electrode Material
Titanium
Device Dimensions
24X32X13cm
Device Weight
2.4Kg
Box sizes
63X35X15cm
Box Weight
3.6Kg
