Gemini AS SERIES User Manual

AS Series
AS-2108BT / AS-2110BT
AS-2112BT / AS-2115BT
1.Channel 1 volume : Adjusts the loudness of the source
connected to CH1
2. LCD: : Displays info for USB/SD/BT/FM radio playback
3.
Channel 2 volume : Adjusts the loudness of the source
connected to CH2
4. Clip LED: Indicates audio clipping.
5.
AUX input（TRS): Connect a digital media player,
etc. to this 1/8" stereo input.
6/11. Mic/Line input switch: Allows user to choose
the MIC or Line signal input.
7/12.
Mic/Line input: Connect a microphone or line
signal to this 1/4" TRS input
8/13:
Mic/Line input: Connect a microphone or line
signal to this XLR input
9:
Channel 3 volume : Adjusts the loudness of the
source connected to CH3
10:
AUX Input (RCA): Connect a CD player, mixer, or
other media source to this line level RCA input.
14:
Master volume : Adjust the loudness of the whole
system.
15:
Bass EQ: Controls the bass(low) frequencies of
speaker at a range between -12dB to + 12dB.
16:
Treble EQ: Controls the treble(high) frequencies of
speaker at a range between -12dB to + 12dB.
17:
Mix Out: Use this XLR output to create a wired
connection to another powered speaker, etc.
18:
Power ON/OFF Switch: Turns unit on or off.
19:
Voltage Switch : Allows user to change the AC
voltage input.
20：
AC Power Input : Mains power supply(supplied
with speaker) plugs in here.
21. MODE : Press to switch Media Playback between
USB/SD/BT/FM Radio. Hold to turn player on/off.
22.
Link: Use to create a wireless pair with another AS
Series Bluetooth™ Speaker.
23.
Transport: Control media player playback.
Play/Pause, Repeat, Skip Forward, Skip Back.
24.
USB port: Insert USB stick for MP3/WAV playback
25.
SD port: Insert SD Card for MP3/WAV playback
