Audio Specifications| quantization | 1 Bit Linear/ Channel, 3 Beam Laser |
|---|---|
| oversampling rate | 8 Times |
| sampling frequency | 44.1 kHz |
| frequency response | 20 Hz to 20 kHz |
| total harmonic distortion | Less Than 0.05% |
| signal to noise ratio | 85 dB |
| dynamic range | 85 dB |
| channel separation | 85 dB (1 kHz) |
| output level | 2.0 +/- 0.2V R.M.S. |
Power| power supply | AC 115/230V, 60/50 Hz |
|---|
Weight and Dimensions| unit dimensions | 19” x 3.5” x 10” (482 x 89 x 254 mm) |
|---|---|
| unit weight | 11.35 lbs (5.14 kgs) |
| remote dimensions | 19” x 3.5” x 3.5” (482 x 89 x 89 mm) |
| remote weight | 3.85 lbs (1.74 kgs) |
Inputs and Outputs| phono input | 3 mV, 47 KOhm |
|---|---|
| line input | 150 mV, 27 KOhm |
| mic input | 1.5 mV, 1 KOhm Balanced |
| max output | 20V Peak-to-Peak |
| rec output | 225 mV, 5 KOhm |
Audio Specifications| sampling frequency | 44.1 kHz |
|---|---|
| frequency response | 20 Hz to 20 kHz |
| total harmonic distortion | Less Than 0.05% |
| signal to noise ratio | 85 dB |
| dynamic range | 85 dB |
| channel separation | 85 dB (1 kHz) |
| output level | 2.0 +/- 0.2V R.M.S. |
Weight and Dimensions| unit dimensions | 19” x 10.2” x 4.3” (482 x 260 x 110 mm) |
|---|---|
| weight | 12.1 lbs (5.5 kgs) |
| shipping weight | 15.6 lbs (7.1 kgs) |
