27
PROGRAMMING (OPTIONAL)
Programming Example:
Program the User 3 Code to “3784”:
1. Select the Program Mode as follows:
(a)
Enter your User Code, followed by R.
(b) Answer NO (press Q ) repeatedly until “TurnOn
Prog Yes/No” is displayed, then press YES (
P).
The display will briefly read: “UPXXXX” then
"User01" (User 1's Code).
2. Press 03 for User No. 3.
3. Press R to advance to the User Code screen.
4. Press 3784 to program the code.
If any other digits are left over from a previous User-3
Code, delete each by pressing
G 0.
Note: Do not attempt to program the "OPTion" or
"ACCess" screens (if they display) as they will not be
saved.
5. Press U to save the code.
6. Press C to exit the Program Mode.
Notes:
•
Note: Duplicate Codes are not allowed; therefore a dupli-
cate Code entered in the LCD Window will erase when
U is
pressed.
• If the system contains more than one keypad, only the
keypad designated “No. 1” may be used for programming
(if in doubt which is No. 1, ask your installer).
• While in Program Mode, the ARMED and STATUS lights
remain off and burglar and fire alarm functions are
disabled.
• In selecting your codes, do not program repetitive
numbers (1111), consecutive numbers (1234), your birth
date, address, or other obvious combinations. Choose a
code of up to six digits (a minimum of four is
recommended, and required in UL installations). If the
keypad detects no Program Mode activity for more than 4
minutes, a tone will sound. Press
C to silence.
