Page 6
DIGITAL DISPLAY:
1. The DIGITAL DISPLAY (20) indicates SPEED (20A), PITCH SLIDE
ACTIVATION (20B), PLAY (20C), PAUSE (20D), REVERSE (20E) and
PITCH PERCENTAGE (20F).
ARM-LIFT HEIGHT ADJUSTMENT:
If the pre-adjusted distance that the CUE LEVER (19) raises the stylus off
the record surface is inadequate, it can be adjusted by turning the ARM-
LIFT HEIGHT ADJUSTMENT SCREW (29) while simultaneously pushing
down on the TONE ARM (6). Clockwise rotation of the screw will decrease
the distance and counterclockwise rotation will increase the distance.
Specifications
TURNTABLE SECTION:
Type...................................................Quartz Direct Drive Manual Turntable
Drive Method................................................................................Direct Drive
Motor......................................................................Brushless DC Motor 18V
Platter............................................Aluminum Diecast 13” (332mm) Dia.
Speed...............................................................................33 1/3, 45 or 78 RPM
Starting Torque..............................................................................2.2 kg/cm
Build-up Characteristics...........................0.6 sec. standstill to 33 1/3 RPM
Braking System....................................................................Electronic Brake
Wow and Flutter.....................................................................0.01% WRMS*
* This rating refers to the turntable assembly and platter only and excludes
effects of records, cartridges or tonearms.
Rumble........................................................................78 dB (IEC 98A WTD)
TONEARM SECTION:
Type...........................................................Universal S-Shaped Tubular Arm
Effective Length.............................................................9 1/16” (230.1 mm)
Arm Height Adjust Range...............................................................0 - 6 mm
Overhang............................................................................19/32" (15.2 mm)
Effective Mass..............................................................9 g (Without Cartridge)
Offset Angle...............................................................................................22°
Friction..................................................Less Than 7 mg (Lateral, Vertical)
Tracking Error Angle............Within 2°32' at the outer groove and within
0°32' at the inner groove of a 30 cm (12") record
Stylus Pressure Adjust Range..........................................................0 - 5 g
Applicable Cartridge Weight Range.................................................6 - 10 g
Headshell Weight.................................................................................5.6 g
GENERAL:
Power Supply...............................................................115V~60Hz/230V~50Hz
Power Consumption..........................................................................15 Watts
Dimensions......................................................................17 3/4” x 6" x 14"
450mm x 152mm x 352 mm
Weight......................................................................................27 lbs. (12.3 kg)
Specifications are subject to change without notice. The weight and dimensions
shown are approximate.
