Page 5
Specifications
Balanced Inputs:
Sensitivity..........................................................................................1 V
RMS
Impedance......................................................................................20 kOhm
Balanced Outputs:
Level...................................................................................................2 V
RMS
Impedance.......................................................................................600 Ohm
Frequency Response:
Stereo Mode.......................................................10 Hz - 60 kHz +0, -1 dB
Circle Surround Mode........................................10 Hz - 22 kHz +0, -1dB
Distortion:
Stereo Mode......................................................................................<0.01%
Circle Surround Mode.......................................................................<0.15%
S/N Ratio:
Stereo Mode......................................................................................>90 dB
Circle Surround Mode Front Channels.............................................>80 dB
Circle Surround Mode Rear Channels.............................................>55 dB
Subwoofer Channel:
Low Pass Filter...........................................................@ 100 Hz, 12 dB/oct
High Pass Filter..............................................................@ 15 Hz, 6 dB/oct
High Pass Filter in Enhanced Mode...........................+ 6 dB @ 40 Hz (Q=2),
12 dB/oct
Rear Channel Effect Max./Min. Ratio................................................12 dB
Power Source.......................................................115V/230V, 60 Hz/50 Hz
Power Consumption.............................................................................10 W
Dimensions...............................19” x 1.75” x 10.5” (483 x 44 x 266 mm)
Weight..................................................................................10.5 lbs (2.5 kg)
Circle Surround and the
symbol are trademarks of SRS Labs, Inc. in
the United States and selected foreign countries. Circle Surround
technology is incorporated under license from SRS Labs, Inc.
is a trademark of Valence Technology Limited, in China, Hong Kong
and Taiwan. CS technology is incorporated with permission of Valence
Technology Limited.
Description Part #
Cabinet Parts and Packing
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Item #
Parts Lists
002-292
031-035
032-070
034-070
022-305
003-998
003-733
003-139
003-140
002-536
002-537
049-206
146-710
196-062
157-963
255-132
153-137
156-089
110-153A
110-158
111-043A
111-046A
111-055
121-003A
PANEL CONTOL
COVER TOP
COVER BOTTOM
PANEL REAR
AC SOURCE FIXER
LED HOLDER 3f (8.5mm)
LED HOUSING
KNOB ROTARY (BIG)
KNOB ROTARY (SMALL)
KNOB PUSH
BUSHING PUSH KNOB
PAD FOOT
GND SCREW
SERIAL NO, LABEL
OWNER’S MANUAL
GIFT BOX
POLYFORM
WARRANTY CARD
PAN-HEAD TAPPING SCREW (TWIN
TOOTH)PAN-HEAD TAPPING SCREW
FLAT-HEAD TAPPING SCREW (5.1-5.3)
BAND-HEAD TAPPING SCREW
BAND-HEAD TAPPING SCREW
BAND-HEAD TAPPING SCREW/TW-E
262-241
262-242
262-243
PRINTED CIRCUIT BOARD SP-1-1
PRINTED CIRCUIT BOARD SP-1-2
PRINTED CIRCUIT BOARD SP-1-3
Description Part #
Printed Circuit Boards
Item #
1
2
3
