8030.LSE PowerPak ™ Data Sheet
Genelec Document BBAGE030. Copyright Genelec Oy 1.2005. All data subject to change without prior notice
International enquiries:
Genelec, Olvitie 5
FIN-74100, Iisalmi, Finland
Phone +358 17 83881
Fax +358 17 812 267
Email genelec@genelec.com
In the U.S. please contact
Genelec, Inc., 7 Tech Circle
Natick, MA 01760
Phone 508 652 0900
Fax 508 652 0909
Email genelec.usa@genelec.com
www.genelec.com
7060A
Subsonic filter
(18 dB/octave) below 29 Hz
Upper bandwidth/LFE cutoff 85 Hz/120 Hz selectable
Connectors
Input 7 XLR female (6 Main + 1 LFE)
Output 7 XLR male (6 Main + 1 Sum Out)
XLR pin sequence pin 1 gnd
pin 2 +
pin 3 -
Input impedance 10 kOhm balanced
Input level for 100 dB SPL
output @ 1 m Variable from +6 to –12 dBu
Crossover frequency,
(sub/main channels) 85 Hz
Crossover slopes
Lowpass 36 dB/octave
Highpass 12 dB/octave
Midband rejection >400 Hz ≥ 50 dB
Bass roll-off control operating From 0 to –6 dB @ 30 Hz
range in 2 dB steps
Phase matching control From 0 to 270° @ 85 Hz
in 90° steps
Bypass Bypasses the bass management for the main channels
LFE sensitivity Adjustable 0 / +10 dB
Redirect Redirects LFE channel signal above 85 Hz to center channel
Sum In Changes subwoofer to Sum In mode, main inputs defeated
Test tone for phase adjustment 85 Hz
Remote LED connector (RJ11) Input for optional Power/Overload+Bypass remote controls
AMPLIFIER SECTION
7060A BASS MANAGEMENT SYSTEMSYSTEM SPECIFICATIONS
7060A 8030A
Free field frequency response 29 Hz…85 Hz 58 Hz...20 kHz
(+/- 3 dB) (Main channels)
Maximum short term sine wave ≥ 108 dB SPL ≥ 100 dB SPL
averaged SPL output
Maximum peak SPL output ≥ 113 dB SPL ≥ 106 dB SPL
Self generated noise level in ≤ 15 dB ≤ 10 dB
free field @ 1 m on axis
(A-weighted)
Harmonic distortion @ 95 dB SPL @ 85 dB SPL
< 2 % < 2 % (50...150 Hz)
< 0.5 % (> 150 Hz)
Drivers (Magnetically shielded) 205 mm (10”) 130 mm (5”) woofer
19 mm (3/4”) dome tweeter
Weight 26 kg (57 lbs) 5.6 kg (12.3 lbs)
Dimensions
Height 527 mm (20 3/4”) 299 mm (11 13/16”)*
Width 462 mm (18 316”) 189 mm (7 7/16”)
Depth 360 mm (14 3/16”) 178 mm (7”)
*Including Iso-Pod™ table stand
7060A 8030A
Short term amplifier output
power (Long term output power
is limited by driver unit
protection circuitry)
Bass 120 W 40 W
Treble N/A 40 W
Amplifier system distortion
at nominal output
THD ≤ 0.05 % ≤ 0.05 %
Mains voltage 220, 230, 240, 100/200 100, 120, 220 or 230 V
or 115/230 V according according to region
to region
Power consumption (average)
Idle 15 VA 10 VA
Full output 150 VA 80 VA
7060A 8030A
Free field frequency response 29 Hz…85 Hz 58 Hz...20 kHz
(+/- 3 dB) (Main channels)
Maximum short term sine wave ≥ 108 dB SPL ≥ 100 dB SPL
averaged SPL output
Maximum peak SPL output ≥ 113 dB SPL ≥ 106 dB SPL
Self generated noise level in ≤ 15 dB ≤ 10 dB
(A-weighted)
Harmonic distortion @ 95 dB SPL @ 85 dB SPL
< 2 % < 2 % (50...150 Hz)
< 0.5 % (> 150 Hz)
Drivers (Magnetically shielded) 205 mm (10”) 130 mm (5”) woofer
19 mm (3/4”) dome tweeter
Weight 26 kg (57 lbs) 5.6 kg (12.3 lbs)
Height 527 mm (20 3/4”) 299 mm (11 13/16”)*
Width 462 mm (18 316”) 189 mm (7 7/16”)
Depth 360 mm (14 3/16”) 178 mm (7”)
*Including Iso-Pod™ table stand
7060A
(18 dB/octave) below 29 Hz
Upper bandwidth/LFE cutoff 85 Hz/120 Hz selectable
Input 7 XLR female (6 Main + 1 LFE)
Output 7 XLR male (6 Main + 1 Sum Out)
XLR pin sequence pin 1 gnd
pin 2 +
pin 3 -
Input impedance 10 kOhm balanced
output @ 1 m Variable from +6 to –12 dBu
(sub/main channels) 85 Hz
Lowpass 36 dB/octave
Highpass 12 dB/octave
Midband rejection >400 Hz ≥ 50 dB
Bass roll-off control operating From 0 to –6 dB @ 30 Hz
range in 2 dB steps
Phase matching control From 0 to 270° @ 85 Hz
Bypass Bypasses the bass management for the main channels
LFE sensitivity Adjustable 0 / +10 dB
Redirect Redirects LFE channel signal above 85 Hz to center channel
Sum In Changes subwoofer to Sum In mode, main inputs defeated
Test tone for phase adjustment 85 Hz
Remote LED connector (RJ11) Input for optional Power/Overload+Bypass remote controls
7060A 8030A
Bass 120 W 40 W
Treble N/A 40 W
THD ≤ 0.05 % ≤ 0.05 %
Mains voltage 220, 230, 240, 100/200 100, 120, 220 or 230 V
or 115/230 V according according to region
to region
Idle 15 VA 10 VA
Full output 150 VA 80 VA
7060A 8030A
Free field frequency response 29 Hz…85 Hz 58 Hz...20 kHz
Maximum short term sine wave ≥ 108 dB SPL ≥ 100 dB SPL
averaged SPL output
Maximum peak SPL output ≥ 113 dB SPL ≥ 106 dB SPL
Self generated noise level in ≤ 15 dB ≤ 10 dB
Harmonic distortion @ 95 dB SPL @ 85 dB SPL
< 2 % < 2 % (50...150 Hz)
< 0.5 % (> 150 Hz)
Drivers (Magnetically shielded) 205 mm (10”) 130 mm (5”) woofer
19 mm (3/4”) dome tweeter
Weight 26 kg (57 lbs) 5.6 kg (12.3 lbs)
Height 527 mm (20 3/4”) 299 mm (11 13/16”)*
Width 462 mm (18 316”) 189 mm (7 7/16”)
Depth 360 mm (14 3/16”) 178 mm (7”)
*Including Iso-Pod™ table stand
7060A 8030A
Bass 120 W 40 W
Treble N/A 40 W
THD ≤ 0.05 % ≤ 0.05 %
Mains voltage 220, 230, 240, 100/200 100, 120, 220 or 230 V
or 115/230 V according according to region
Idle 15 VA 10 VA
Full output 150 VA 80 VA
8030.LSE POWERPAK ACOUSTIC SPECIFICATIONS
8030.LSE PowerPak
Recommended listening 1.7 to 2.5 m (5 to 8 ft)
distance
Typical max short term 108 dB, Flat response weighting
RMS SPL all channels driven
Suggested acoustic space max. 85 m
3
(3000 cubic feet)
8030.LSE PowerPak
Recommended listening 1.7 to 2.5 m (5 to 8 ft)
distance
Typical max short term 108 dB, Flat response weighting
Suggested acoustic space max. 85 m
