10
High Pressure Washer
How to Use the Adjustable
Nozzle
You now should know how to START your pressure
washer and how to STOP it. The information in this
section will tell you how to adjust the spray pattern
and apply detergent or any other cleaning chemicals.
DANGER! Never adjust spray pattern
when spraying. Never put hands in front
of nozzle to adjust spray pattern.
On the end of your spray gun is a nozzle that you can
slide forward and backward and that you can also
twist from side to side. With the adjustable nozzle you
can adjust the spray pattern to be either high pres-
sure or low pressure. You can also adjust the spray
so it is concentrated in a stream pattern or expanded
into a fan pattern.
Slide the nozzle forward when you wish to adjust
the spray to low pressure mode (Figure 11). Slide
the nozzle backward to achieve high pressure.
Point the nozzle toward the ground and press the
trigger to test the pattern (Figure 12).
Twisting the nozzle adjusts the spray pattern from a
narrow pattern to a fan pattern.
For most effective cleaning, keep spray nozzle
between 8 to 24 inches away from cleaning sur-
face.
If you get spray nozzle too close, especially using
high pressure mode, you may damage the cleaning
surface.
Do not get closer than 6 inches when cleaning
automobile tires.
Figure 11 — Using the adjustable nozzle.
Slide Nozzle Backward
for High Pressure
Mode
Slide Nozzle Forward
for low pressure
mode and detergent
application
Twist nozzle counter-
clockwise for fan
spray pattern
Twist nozzle clock-
wise for narrow
spray pattern
Figure 12 — Testing the spray pattern.
