High Pressure Washer
5
Read entire Owners manual before you attempt to
assemble or operate your new pressure washer.
Your new pressure washer has been assembled at
the factory with exception of those parts left unassem-
bled for shipping purposes.
REMOVE PRESSURE
WASHER FROM CARTON
Remove parts box included with pressure washer.
Slice two corners at guide handle end of carton
from top to bottom so the panel can be folded down
flat, then remove all packing material.
Roll pressure washer out of carton.
CARTON CONTENTS
Items in the carton include:
Main Unit
Parts Box (which includes the following):
Wireform
Goggles
Nozzle Cleaning Kit
Owners Manual
Engine Manual
Spray Gun
Nozzle Extension
High Pressure Hose
Handle
Parts Bag (which includes the following):
2 carriage bolts
2 knobs
If any of the above parts are missing or damaged, call
the pressure washer helpline at 18002701408.
PREPARING THE PRESSURE
WASHER FOR USE
If you have any problems with the assembly of your
pressure washer or if parts are missing or damaged,
call the Pressure Washer Helpline at 1-800-270-1408.
To prepare your pressure washer for operation you
will need to perform these tasks:
Attach the handle and attach the wire form that
holds high pressure hose and spray gun.
Connect high pressure hose to the spray gun and
the pump and connect water supply to the pump.
Add oil to engine crankcase.
Add fuel to fuel tank.
Attach the Handle
Place the top of the handle onto the bottom of the
handle already connected to the main unit making
sure the holes in the top align with the holes on the
bottom. (Figure 1)
Generac 1600PSI High Pressure Washer
