6
High Pressure Washer
Insert the carriage bolts through the holes as shown
in Figure 2 and attach the plastic knobs. Tighten
the knobs by hand. (Figure 2)
Insert the wire support with the longer arm positioned
on the left. From this view the hook should resemble a
J.
(Figure 3)
Add Engine Oil
IMPORTANT: Any attempt to crank or start the
engine before it has been properly serviced with the
recommended oil may result in an engine failure.
Note: When adding oil to the engine crankcase, use
only high quality detergent oil rated with API service
classification SF,SG, SH or SH/CD rated SAE 30
weight. Select the oils viscosity grade according to
your expected operating temperature. Do Not Use
SAE 10W40 Oil.
Although multi-viscosity oils (5W30, 10W30, etc.)
improve starting in cold weather, these multi-viscosity
oils will result in increased oil consumption when used
above 32°F. Check your engine oil level more fre-
quently to avoid possible damage from running low on
oil.
Place pressure washer on a level surface.
Clean area around oil fill and remove oil dipstick
(Figure 4)
Wipe dipstick clean. Pour oil into oil fill opening until
oil reaches FULL mark on the dipstick. Stop occa-
sionally to check oil level. DO NOT OVERFILL.
Install oil dipstick, hand tighten securely.
Note: Check Oil Often During Engine Breakin.
Add Gasoline
DANGER! Never fill fuel tank indoors.
Never fill fuel tank when engine is run-
ning or hot. Do not smoke when filling
fuel tank.
WARNING! Never fill fuel tank completely
full. Fill tank to about 1/2" below the
bottom of the filler neck to provide space
for fuel expansion. Wipe away any fuel
spillage from engine and equipment
before starting.
The manufacturer recommends fresh, clean unleaded
regular automotive gasoline.
Use clean fuel and store in approved, clean cov-
ered containers. Use clean fill funnels. Never use
stale gasoline left over from last season or gaso-
line stored for long periods.
Figure 3 — Fit wire form on handle.
Figure 4 — Add oil to engine crankcase. Do not
attempt to start engine without
adding oil.
Oil Fill Cap
Figure 2 — Insert the carriage bolts and attach
the knobs.
colder 32°F warmer
5W30 SAE 30
