AA
SSSSEEMMBBLL
YY
7
High Pressure Washer
Clean area around fuel fill cap, remove cap
(Figure 5).
Add UNLEADED regular gasoline, slowly, to fuel
tank. Use a funnel to prevent spillage.
Install fuel cap and wipe up any spilled gasoline.
Connect Hose and Water
Supply to Pump
IMPORTANT: You must assemble wand and attach
all hoses before you start engine. Starting engine
without all hoses connected and water supplied will
damage pump.
Uncoil high pressure hose and attach one end of
hose to the base of the spray gun (Figure 6).
Tighten by hand.
Attach other end of high pressure hose to the high
pressure fitting on the pump (Figure 7). Tighten by
hand.
Before you connect your garden hose to the water
inlet, inspect the Inlet Screen (see Figure 7). Clean
the screen if it contains debris or have it replaced if
damaged. DO NOT RUN THE PRESSURE
WASHER IF THE SCREEN IS DAMAGED.
Connect garden hose to water inlet. Tighten by
hand. (Figure 8)
Turn ON the water.
Squeeze trigger on gun to purge pump system of
air and impurities.
CAUTION: Before starting the pressure
washer, be sure you are wearing ade-
quate eye protection.
Figure 7 — Connect high pressure hose to
pump.
Figure 6 — Connect high pressure hose
to spray gun.
Figure 8 — Connect the garden hose to water
inlet and turn ON the water.
Figure 5 — Add gasoline to fuel tank.
Gas Cap
Connect High Pressure
Hose Here
To Next Page
