KNOW YOUR PRESSURE WASHER
Read this owners manual and safety rules before operating your high pressure washer.
Compare the illustrations with your high pressure washer to familiarize yourself with the locations of various
controls and adjustments. Save this manual for future reference.
Generac 2700PSI High Pressure Washer
GENERAC
The Reliable Ones
5
Pump Develops high pressure.
Spray Gun Controls the application of water and
chemical onto cleaning surface with trigger device.
Includes safety latch.
Chemical Valve Handle The handle allows you to
select the high pressure spray or the chemical spray
(located on the wand).
Dual Element Air Cleaner Uses a dry type filter
element and foam pre-cleaner to limit the amount of
dirt and dust that gets in the engine.
Water Inlet Connection for garden hose.
Dual Lance Must be connected to the spray gun.
High Pressure Hose Connect one end to water
pump and the other end to spray wand.
High Pressure Outlet Connection for high pressure
hose.
Spark Arrestor Muffler Exhaust muffler lowers
engine noise and is equipped with a spark arrestor
screen, a USDA mandate for engine use in national
forests and parks.
Goggles Always use the enclosed goggles or other
eye protection when running your pressure washer.
Automatic Cool Down System Cycles water
through pump when water reaches 140°-145°F. Warm
water will discharge from pump onto base of unit.
This system prevents internal pump damage.
Gas Tank Fill with regular unleaded gasoline.
Chemical Concentration Knob Adjust concentra-
tion of chemical here.
Pressure Control Knob Adjust pressure output
here.
Primer Bulb Used for starting a cold engine.
Spray Gun
Chemical Valve Handle
High Pressure Hose
Goggles
Dual Element
Air Cleaner
Gas Tank
Water Inlet
Pump equipped with
Automatic Cool Down System
High Pressure Outlet
Pressure Control
Knob
Spark Arrestor
Muffler
Primer Bulb
Dual Lance
Chemical
Concentration Knob
