Generac 2700PSI High Pressure Washer
GENERAC
The Reliable Ones
7
ASSEMBLY
Insert the carriage bolts from the outside through
the holes on the handle and attach the plastic
knobs on the inside. Tighten the knobs by hand
(Figure 2).
Insert the wire support with the longer arm positioned
on the left. From this view (from rear of unit), the hook
resembles a J
(Figure 3)
.
Add Engine Oil
IMPORTANT: Any attempt to crank or start the
engine before being properly serviced with the
recommended oil will result in an engine failure.
Note: When adding oil to the engine crankcase, use
only high quality detergent oil rated with API service
classification SF,SG, SH or SH/CD rated SAE 30
weight. Select the oils viscosity grade according to
your expected operating temperature. Do Not Use
SAE 10W40 Oil.
Although multi-viscosity oils (5W30, 10W30, etc.)
improve starting in cold weather, these multi-viscosity
oils will result in increased oil consumption when used
above 32°F. Check your engine oil level more
frequently to avoid possible damage from running
low on oil.
Place pressure washer on a level surface.
Clean area around oil fill and remove yellow oil fill
cap (Figure 4).
Pour oil into the oil fill opening until it reaches the
top of the oil fill hole. DO NOT OVERFILL.
Install yellow oil cap, hand tighten securely.
Note: Check Oil Often During Engine Breakin.
Add Gasoline
DANGER! Never fill fuel tank indoors.
Never fill fuel tank when engine is running
or hot. Do not smoke when filling fuel tank.
WARNING! Never fill fuel tank completely
full. Fill tank to about 1/2" below the bottom
of the filler neck to provide space for fuel
expansion. Wipe away any fuel spillage
from engine and equipment before starting.
The manufacturer recommends fresh, clean unleaded
automotive gasoline.
Use clean fuel and store in approved containers.
Use clean fill funnels. Never use stale gasoline
left over from last season or gasoline stored for long
periods.
Figure 3 — Fit wire form on handle.
Figure 4 — Add oil to engine crankcase. Do not
attempt to start engine without
adding oil.
Figure 2 — Insert the carriage bolts and attach
the knobs.
colder 32°F warmer
5W30 SAE 30
Yellow
Oil Fill Cap
