Generac Portable Products 2,300 PSI High Pressure Washer
17
PARTS LIST î UNIT
Item Part # Qty. Description
1 AB5721 1 BASE
2 52858 8 LOCKNUT, M8
3 42909 2 HHCS, M8 1.25 x 30
4 50190 2 WASHER, Flat .34" x 1"
5 27007 2 MOUNT, Donut Type Vibration
7 B4099 1 DECAL, IMP. Purge Air
8 B2150 1 HOOK, Gun
9 B2516 1 CAP, Vinyl (black)
10 B2043 7 BOLT, 5/16"-18 x 1-3/4"
Carriage
11 B5713 1 DECAL, Logo
12 B1983 1 HANDLE
13 B1631A 1 BILLBOARD, Plastic
14 B1932 1 DECAL, Instructions
15 99583 8 NUT, Flange Lock 5/16"-18
16 B1981 2 SUPPORT, Handle
17 65852A 1 SPRING CLIP, Holder
18 185954 1 SCREW, Self Tap #8 - 18 x
1/2"
20 21217 4 MOUNT, Rubber Shock
21 B1232 1 CLAMP, Hose 7/16" Dia.
23 A1040D 1 HOSE, 4-1/2' Chemical Clear
24 A1041 1 FILTER, Chemical Hose
26 97178 2 KNOB, Handle 1/4" - 20 PW
27 31669 2 BOLT, 1/4" - 20 x 1-3/4"
Carriage
28 B4966 2 ASSEMBLY, 10" Tire & Wheel
Item Part # Qty. Description
29 75402C 2 PUSHNUT, 5/8" Dia.
30 B4095 1 SHEET, Info
31 NSP 1 MANUAL, Engine
32 B5715 1 MANUAL
33 23139B 1 KEY, 3/16" sq. x 1-1/2"
34 95531 4 SHCS, 5/16" - 24 x 3/4"
35 187264 1 ASSEMBLY, Complete Pump
(see pages 18-21)
39 B1982 1 BUMPER
40 NSP 1 ENGINE
41 B5830 1 KIT, "O" Ring
42 B5694 1 HOSE, High Pressure
43 87815 1 GOGGLES, Safety
44 B3263A 1 GUN, High Pressure
45 B3335C 1 LANCE, Nozzle Hi/Lo
46 97566 1 TAG, Nozzle Instructions
47 B2168A 1 HANGER, Hose, Gun, Jug
48 B4224 1 SCREEN, Gun Inlet
49 B2163 1 KIT, Nozzle Cleaning
50 97837 1 O-RING, Hi Pressure
51 92661 1 NOZZLE, 1.20 Blue
Replacement
53 92479 4 LOCKWASHER, Ribbed
54 BB3061B 1 OIL
55 48031G 1 CLAMP, Hose
56 52858 2 NUT, Locking M8 - 1.25
To Next Page
