Generac Portable Products 2700PSI High Pressure Washer
Read entire owners manual before you attempt to
assemble or operate your new pressure washer. Your
new pressure washer has been assembled at the
factory with the exception of those parts left
unassembled for shipping purposes.
REMOVE PRESSURE
WASHER FROM CARTON
Remove parts box included with pressure washer.
Slice two corners at guide handle end of carton
from top to bottom so the panel can be folded down
flat, then remove all packing material.
Roll pressure washer out of carton.
Carton Contents
Items in the carton include:
Main Unit
Manual Bag
Owners Manual
Engine Owners Manual
Nozzle Cleaning Kit
ORing Maintenance Kit
StaBil® Brochure
StaBil®
Owner Registration Card
Parts Box (which includes the following):
Video
Engine Oil
Wireform
Goggles
Spray Gun
Dual Lance
High Pressure Hose
Handle
Handle Parts Bag (which includes the following):
2 carriage bolts
2 knobs
PREPARING PRESSURE
WASHER FOR USE
If you have any problems with the assembly of your
pressure washer or if parts are missing or damaged,
call the Pressure Washer Helpline at 1-800-270-1408.
To prepare your pressure washer for operation you
will need to perform these tasks:
Remove shipping cap from your pump and install oil
dipstick.
Attach the handle and attach the wire form that
holds high pressure hose and spray gun.
Connect high pressure hose to the spray gun and
the pump and connect water supply to the pump.
Add oil to engine crankcase.
Add fuel to fuel tank.
Remove Shipping Cap / Install Oil
Dipstick
To prevent oil from leaking from the pump, a shipping
cap has been installed on the oil breather of the
pump.
You must remove the shipping cap and the install oil
dipstick for your pressure washer to operate properly
(Figure 1).
Running unit with the shipping cap installed will
damage the pump and void your warranty.
Figure 1 Remove shipping cap and install oil
Shipping Cap
Oil Dipstick
Remove shipping cap and
install oil dipstick here.
