Generac Portable Products 2,100 PSI High Pressure Washer
4
KNOW YOUR PRESSURE WASHER
Read this owners manual and safety rules before operating your high pressure washer.
Compare the illustrations with your high pressure washer to familiarize yourself with the locations of various
controls and adjustments. Save this manual for future reference.
Adjustable Nozzle Always attached to nozzle
extension. Adjustable nozzle allows you to adjust
spray pressure and spray pattern.
Air Cleaner Dry type filter element limits the
amount of dirt and dust that gets in the engine.
Automatic Cool Down System Cycles water
through pump when water reaches 140°-145°F. Warm
water will discharge from pump onto ground. This
system prevents internal pump damage.
Choke Lever Prepares a cold engine for starting.
High Pressure Hose Connect one end to water
pump and the other end to spray gun.
High Pressure Outlet Connection for high
pressure hose.
Oil Fill/Dipstick Check and fill with oil here.
Pump Develops high pressure.
Recoil Starter Used for starting the engine
manually.
Spray Gun Controls the application of water onto
cleaning surface with trigger device. Includes safety
latch.
Throttle Control Lever Sets engine in starting
mode for recoil starter and stops a running engine.
Water Inlet Connection for garden hose.
High Pressure Hose
Adjustable Nozzle
Throttle Control Lever
High Pressure Outlet
Pump equipped with
Automatic Cool Down
System
Spray Gun
Water Inlet
Oil Fill/Dipstick
Recoil Starter
Choke Lever
Air Cleaner
