Generac Portable Products 2,100 PSI High Pressure Washer
5
Read entire owners manual before you attempt
to assemble or operate your new pressure
washer.
REMOVE PRESSURE
WASHER FROM CARTON
Remove the high pressure hose and parts box
included with pressure washer.
Slice two corners at the end of carton from top to
bottom so the panel can be folded down flat, then
remove all packing material.
Roll pressure washer out of carton.
Carton Contents
Items in the carton include:
Main Unit
Parts Box (which includes the following):
Wireform
Goggles
Handle Assembly
Handle Fastening Hardware
Nozzle Cleaning Kit
High Pressure Hose
Owners Manual
Engine Manual
Owners Registration Card
Spray Gun
Nozzle Extension
Oil Bottle
O-Ring Maintenance Kit
If any of the above parts are missing or damaged, call
the pressure washer helpline at 18002701408.
PREPARING PRESSURE
WASHER FOR USE
If you have any problems with the assembly of your
pressure washer or if parts are missing or damaged,
call the pressure washer helpline at 1-800-270-1408.
To prepare your pressure washer for operation,
you will need to perform these tasks:
Attach the handle and wire form.
Add oil to the engine crankcase.
Add fuel to the fuel tank.
Connect the high pressure hose to the spray gun
and the pump.
Connect the water supply to the pump.
Attach Handle and Wire Form
NOTE: All assembly operations given in this section
will be described from the perspective of assembling
the pressure washer from the rear.
Place the handle onto the handle supports already
connected to the main unit. Make sure the holes in
the handle align with the holes on the handle
supports (Figure 1).
NOTE: It may be necessary to move the handle
supports from side to side in order to align the handle
so it will slide over the handle supports.
Make sure the
holes on the
handle are
aligned with
the holes on
the handle
supports
Handle
Handle
Supports
Figure 1 Attach Handle to Base
