Generac Portable Products 2,100 PSI High Pressure Washer
7
Attach the other end of the high pressure hose to
the high pressure fitting on the pump (Figure 7).
Tighten by hand.
Before you connect your garden hose to the water
inlet, inspect the inlet screen (Figure 8). Clean the
screen if it contains debris, replace it if it is
damaged. DO NOT RUN THE PRESSURE
WASHER IF THE SCREEN IS DAMAGED.
Run water through your garden hose for 30 seconds
to clean out any debris. Turn off water.
Connect the garden hose to the water inlet. Tighten
by hand (Figure 8).
WARNING! There MUST be at least ten feet
of unrestricted garden hose between the
pressure washer inlet and any flow shut off
device, such as a Y shut-off connector or other
convenience-type water shut-off valve. Damage
to pressure washer resulting from disregarding
this warning will not be covered by the warranty.
Turn ON the water and squeeze the trigger on the
spray gun to purge the pump system of air and
impurities.
CAUTION: Before starting the pressure
washer, be sure you are wearing adequate eye
protection.
CHECKLIST BEFORE
STARTING ENGINE
Review the units assembly to confirm you have
performed all of the following:
Make sure the handle and wire form are in place
and secure.
Check that oil has been added to the proper level in
the engine crankcase.
Add the proper gasoline to fuel tank.
Check for properly tightened hose connections.
Check to make sure that there are no kinks, cuts, or
damage to the high pressure hose.
Provide a proper water supply (not to exceed 140°F)
at an adequate flow.
Be sure to read Safety Rules and How To Start
Your Engine before using the pressure washer.
Connect High Pressure
Hose Here
Figure 6 Connect High Pressure Hose to Spray Gun
Figure 7 Connect High Pressure Hose to Water
Outlet
Inlet Screen
Figure 8 Connect Garden Hose to Water Inlet
