Generac Portable Products 2,300 PSI Pressure Washer
7
Attach the other end of the high pressure hose to
the high pressure outlet on the pump (Figure 6).
Tighten by hand.
Before you connect your garden hose to the water
inlet, inspect the inlet screen (Figure 7). Clean the
screen if it contains debris or have it replaced if
damaged. DO NOT RUN THE PRESSURE
WASHER IF THE SCREEN IS DAMAGED.
Run water through your garden hose for 30 seconds
to clean out any debris.
Connect the garden hose to the water inlet. Tighten
by hand (Figure 7).
WARNING! There MUST be at least ten feet
of unrestricted garden hose between the
pressure washer inlet and any flow shut off
device, such as a Y shut-off connector or other
convenience-type water shut-off valve. Damage
to pressure washer resulting from disregarding
this warning will not be covered by the warranty.
Turn ON the water and squeeze the trigger on the
gun to purge the pump system of air and impurities.
CAUTION! Before starting the pressure
washer, be sure you are wearing adequate eye
protection.
CHECKLIST BEFORE
STARTING ENGINE
Review the units assembly to ensure you have
performed all of the following.
Check that the handle is secure.
Check that the wireform is properly installed.
Check that oil and fuel has been added to the
engine.
Check for properly tightened hose connections.
Check to make sure that there are no kinks, cuts, or
damage to the high pressure hose.
Provide a proper water supply (not to exceed
140° F) at an adequate flow.
Be sure to read Safety Rules and How To Start
Your Engine before using the pressure washer.
Connect high
pressure hose
here.
Connect
high
pressure
hose here.
Inspect inlet
screen, Do Not
use if damaged;
clean if dirty.
Figure 5 Connect High Pressure Hose to Spray Gun
Figure 6 Connect High Pressure Hose to Pump
Figure 7 Connect the Garden Hose to Water Inlet
