Generac Portable Products 2,300 PSI Pressure Washer
6
Insert the carriage bolts through the holes on the
handle and attach the plastic knobs. Tighten the
knobs by hand (Figure 2).
Insert the wire support with the longer arm
positioned on the right, as viewed from the rear of
the unit. The chemical bottle hook should resemble
a J (Figure 3).
Add Engine Oil
IMPORTANT: Any attempt to crank or start the engine
before it has been properly serviced with the
recommended oil may result in an engine failure.
Place pressure washer on a level surface.
Refer to the engine owners manual to add
recommended oil to engine.
NOTE: Check oil often during engine breakin. Refer
to engine owners manual for recommendations.
NOTE: The pump is pre-lubricated and sealed,
requiring no additional lubrication for the life of the
pump.
Add Gasoline
DANGER! Never fill fuel tank indoors. or when
engine is running or hot. Do Not smoke when
filling fuel tank.
WARNING!
Never fill fuel tank completely full.
Fill tank to provide space for fuel expansion.
Wipe away any fuel spillage from engine and
equipment before starting.
Use clean fuel and store in approved, clean covered
containers. Use clean fill funnels. Never use stale
gasoline left over from last season or gasoline
stored for long periods.
Clean the area around the fuel fill cap, remove the
cap (Figure 4).
Slowly add regular unleaded gasoline to fuel tank.
Use a funnel to prevent spillage.
Install the fuel cap and wipe up any spilled gasoline.
Connect Hose and Water Supply to
Pump
IMPORTANT: You must attach all hoses before you
start the engine. Starting engine without all hoses
connected and water supplied will damage the pump.
Uncoil the high pressure hose and attach one end of
the hose to the base of the spray gun (Figure 5).
Tighten by hand.
Maximum Fuel
Level
Fuel Level
Mark
Longer Arm
Figure 4 Add Gasoline to Fuel Tank
Figure 2 Secure Handle
Figure 3 Attach Wire Form to Handle
To Next Page
