Generac Portable Products 2,300 PSI Pressure Washer
5
Read entire owners manual before you attempt
to assemble or operate your new pressure
washer.
REMOVE PRESSURE
WASHER FROM CARTON
 Remove the handle and parts box included with
pressure washer.
 Slice two corners at the end of carton from top to
bottom so the panel can be folded down flat, then
remove all packing material.
 Roll pressure washer out of carton.
CARTON CONTENTS
Items in the carton include:
 Main Unit
 Parts Box (includes the following):
- Adjustable Nozzle Extension
- Emissions Control Warranty
- Engine Manual
- Engine Warranty
- Goggles
- Handle and Handle Hardware Bag
- High Pressure Hose
- Nozzle Cleaning Kit
- O-Ring Maintenance Kit
- Oil Bottle
- Owner's Manual
- Spray Gun
- Warranty Card
- Wireform
If any of the above parts are missing or damaged, call
the pressure washer helpline at 18002701408.
PREPARING PRESSURE
WASHER FOR USE
If you have any problems with the assembly of your
pressure washer or if parts are missing or damaged,
call the pressure washer helpline at 18002701408.
To prepare your pressure washer for operation
you will need to perform these tasks:
 Attach the handle and wire form.
 Add oil to the engine.
 Add fuel to the fuel tank.
 Connect the high pressure hose to the spray gun
and the pump.
 Connect the water supply to the pump.
Attach the Handle
 Place the handle onto the handle supports already
connected to the units base. Make sure the holes in
the handle align with the holes on the handle
supports (Figure 1).
NOTE: It may be necessary to move the handle
supports from side to side in order to align the handle
so it will slide over the handle supports.
Make sure the
holes on the
handle are
aligned with
the holes on
the handle
supports
Handle
Handle
Supports
Figure 1  Attach Handle to Base
