Generac Power Systems GP6500 Repair Manual

Page 59
DISASSEMBLY
SECTION 4.1
MAJOR DISASSEMBLY
PART 4
ITEM QTY. DESCRIPTION
1 1 ENGINE, 208CC
2 1 RECOIL ASSEMBLY
3 1 CARBURETOR
4 1 AIR CLEANER COVER
5 1 AIR FILTER
6 3 CARBURETOR GASKET
7 1 SPARK PLUG BOOT
8 1 OIL LEVEL SENSOR
9 1 FRAME, 3250W
10 1 FUEL SHUTOFF VALVE
11 2 VIBRATION MOUNT, #1
12 2 VIBRATION MOUNT, #2
13 1 AVR
14 1 BRUSH ASSEMBLY
15 1 SPARK ARRESTOR
16 1 MUFFLER ASSEMBLY
17 1 FUEL TANK ASSEMBLY
18 1 FUEL TANK CAP ASSEMBLY
19 1 CONTROL PANEL ASSEMBLY
20 2 WHEEL, 7” DIAMETER 3250W
21 2 WHEEL AXLE M12-1.75 THREADS
22 2 NUT, AXLE M12-1.75
23 2 WASHER, FLAT M12
24 2 COTTER PIN
25 2 BUMPER BRACKET 3250W
26 7 NUT, FLANGE M6-1.0
27 2 RUBBER BUMPER, 3250W
ITEM QTY. DESCRIPTION
28 5 BOLT, FLANGE M6-1.0 X 40
29 2 BOLT, FLANGE M6-1.0 X 16
30 1 RUBBER GRIP, HANDLE 3250W
31 1 HANDLE, PORTABLE 3250W
32 1 ASSY, HANDLE BRACKET 3250W
33 1 ASSEMBLY, ALTERNATOR BRUSH
TYPE 3250W
