Page 63
DISASSEMBLY
SECTION 4.1
MAJOR DISASSEMBLY
PART 4
ITEM QTY. DESCRIPTION
2 1 ASSY CRADLE BASE
3 1 CRADLE END
3A 1 ASSEMBLY, FRAME 1 PIECE
4 1 PANEL RAIL
5 1 BACK RAIL
6 10 CURVED HEAD BOLT M8-1.25 X 42MM
7 11 CAP NUT LOCKING M8-1.25
9 1 ENGINE, 389cc W /0 MUFFLER
10 4
VIB MOUNT RUBBER 35MM X 25.4 X
M8-1.25
11 4 WASHER LOCK M8-5/16
12 4 SCREW HHC M8-1.25 X 30
13 8 NUT LOCK FLG M8-1.25
14 2 WASHER FLAT 13mm
15 1 ALTERNATOR
15A * AVR
15B * BRUSH-ALTERNATOR
15C 1 SCROLL, ALTERNATOR, SKU
16 3 SCREW HHC M5-0.8 X 8 PC8.8
17 1 CLAMP HOSE .38-.87
18 1 FUEL HOSE, 4 ID, 8.5 OD X 120MM
20 4 SCREW PPPH #8-16 X 1/2" BZC
21 1 ASSY RCP PANEL 25A RD W/HR MTR
22 1 ASSY GND WIRE ALT TO BASE
23 1 WASHER LOCK SPECIAL 1/4"
24 1 LUG SLDLSS #2-#8 X 17/64 CU
ITEM QTY. DESCRIPTION
25 1 SCREW HHTT M6-1.0 X 25
27 1 FUEL TANK ASSY 6.6 GAL PORTABLE
28 4 SCREW HHTT M8-1.25 X 20
29 1 FUEL CAP, VENTED
30 1 SHIELD, HEAT, SKU
31 1 BRACKET, MUFFLER 389CC
32 1 MUFFLER, 389CC
33 1 GASKET, EXHAUST 389CC
34 4 SCREW HHTT M6-1.0 X 12
35 4 WASHER FLAT 5/16-M8 ZINC
36 4 WASHER LOCK M8-5/16
37 4 SCREW HHC MB-1.25 X 20 G8.8 FT
38 2 STUD M8-1.25 X 35 G5 ZINC
39 2 HEX NUT M8-1.25 G8 CLEAR ZINC
44 1 ASSY HANDLE LH
45 4
CARRIAGE HEAD BOLT M8-1.25 X
46mm LONG
47 1 ASSY HANDLE RH
48 2
TIRE 9,5" DIA RUN FLAT PLASTIC HUB/
RUBBER TREAD
49 2 AXLE PIN, 1/2" X 4", 3/4" HEAD
50 2 COTTER PIN, 1/8" X 1 1/4" ZN PLT
51 1 FRAME, BENT, FOOT
52 2 RUBBER FOOT, M8-1.25
54 2 WASHER FLAT 5/16-M8 ZINC
55 2 SCREW HHC M8-1.25 X 15
