Generac Power Systems GP6500 Repair Manual

Page 67
DISASSEMBLY
SECTION 4.1
MAJOR DISASSEMBLY
PART 4
ITEM QTY. DESCRIPTION
1 1 CRADLE END
2 1 BACK RAIL
3 10
CURVED HEAD BOLT 5/16-18 x 1.625"
LONG
4 10
CAP NUT LOCKING 5/16-18 THREAD,
5/16" OF THREAD
5 1 PANEL RAIL
6 1 ASSY CRADLE BASE
10 3 WASHER LOCK M8-5/16
11 3 SCREW HHC 3/8-16 x 1-1/4 G5
12 1 SCREW HHC 5/16-24 x 1-1/4 G5
13 2 SCREW HHC 5/16-18 x 1-1/4 G5
14 3 WASHER LOCK M10
15 8 NUT LOCK FLG 5/16-18
16 1 ALTERNATOR, 7000W
17 2
VIB MOUNT RUBBER 1.38 x 1.0 x
5/16-18 MALE/FEMALE
18 1 ENGINE, GH410
19 1 BRACKET, MOUNT
20 2
VIB MOUNT RUBBER 1.38 x 1.0 x
5/16-18 M/M
21 2 WASHER LOCK M6-1/4
22 2 WASHER FLAT 5/16-M8 ZINC
23 2 WASHER FLAT 1/4-M6 ZINC
24 2 SCREW HHC 5/16-18 x 1-1/2 G5
25 2 SCREW HHC M6-1.0 x 16 C8,8
26 1 BRACKET, MOUNTING, MUFFLER 410
27 1
CLAMP HOSE .38-.87 [NOT SHOWN,
FUEL HOSE]
28 1 CAPACITOR, VOLTAGE REG VS
ITEM QTY. DESCRIPTION
30 1 LUG SLDLSS #2-#8 X 17/64 CU
31 1 WASHER LOCK SPECIAL 1/4"
32 4 SCREW PPPH #8-16 x 1/2" BZC
33 1 ASSY GND WIRE ALT TO BASE
34 1
RECEPTACLE PANEL 30A RND W/HR
MTR
35 1 SCREW HHTT M6-1.0 x 25 BP
55 1 ACCESSORY KIT
56 1 ASSY HANDLE LH
57 4 CHB CUSTOM 5/16 18 x 46MM LONG
58 2
CAP NUT LOCKING 5/16-18, 5/16" OF
THREAD
59 1 ASSY HANDLE RH
60 2
TIRE 9.5" DIA RUN FLAT PLASTIC
HUB/RUBBER TREAD
61 2 SCREW, HHC 1/2"-13 x 4-1/2" LONG
62 2
NUT, LOCK HEX 1/2-13 NYLON
INSERT
63 1 FRAME, BENT, FOOT
64 2 RUBBER FOOT
65 4 NUT LOCK FLG 5/16-18
66 2 WASHER FLAT 5/16-M8 ZINC
67 2 SCREW HHC 5/16-18 X 1/2 G5
68 1 FRAME, BENT, FOOT SUPPORT
69 2 WASHER FLAT 1/2 ZINC
70 4 SCREW HHTT M8-1.25 X 20
71 1 FUEL TANK ASSY 8.0 GAL PORTABLE
72 1 FUEL CAP-VENTED
