Page 69
DISASSEMBLY
SECTION 4.1
MAJOR DISASSEMBLY
PART 4
ITEM QTY. DESCRIPTION
1 1 CRADLE END
2 1 BACK RAIL
3 10
CURVED HEAD BOLT 5/16-18 x 1.625"
LONG
4 10
CAP NUT LOCKING 5/16-18 THREAD)
5/16" OF THREAD
5 1 PANEL RAIL
6 1 ASSY CRADLE BASE
10 2 WASHER FLAT 5/16-M8 ZINC
11 2 NUT HEX LOCK M8-1.25 NY INS
12 2
VIBE MOUNT 25.0 x 31.8 x M8-1.25
M/M
13 4 NUT LOCK FLG 5/16-18
14 1 ASSEMBLY ENGINE GH-410
15 1 ALTERNATOR 8000W
16 2
VIB MOUNT RUBBER 1.38 x 1.0 x
5/16-18 MALE/MALE
17 2 WASHER LOCK M6-1/4
18 2 WASHER FLAT 1/4-M6 ZINC
19 2 SCREW HHC M6-1.0 x 16 C8.8
20 1 SCREW HHTR 5/16-18 x 3/4
21 1 BRACKET MUFFLER
22 4 SCREW FHSC 3/8-16 x 3/4
23 1
CLAMP HOSE .38-.87 [NOT SHOWN,
FUEL HOSE]
30 1 LUG SLDLSS #2-#8 x 17/64 CU
31 1 WASHER LOCK SPECIAL 1/4"
32 4 SCREW PPPH #8-16 x 1/2" BZC
33 1 ASSY GND WIRE ALT TO BASE
34 1 ASSY RCP PNL 8KW 30A W/HR MTR
35 1 SCREW HHTT M6-1.0 x 25 BP
55 1 ACCESSORY KIT
56 1 ASSY HANDLE LH
57 4 CHB CUSTOM 5/16 18 x 46MM LONG
58 2
CAP NUT LOCKING 5/16-18, 5/16" OF
THREAD
59 1 ASSY HANDLE RH
ITEM QTY. DESCRIPTION
60 2
TIRE 9.5" DIA RUN FLAT PLASTIC
HUB/RUBBER TREAD
61 2 SCREW, HHC 1/2"-13 x 4-1/2" LONG
62 2
NUT, HEX LOCK 1-2"-13 NYLON
INSERT
63 1 FRAME, BENT, FOOT
64 2 RUBBER FOOT
65 4 NUT LOCK FLG 5/16-18
66 2 WASHER FLAT 5/16-M8 ZINC
67 2 SCREW HHC 5/16-18 x 1/2 G5
68 1 FRAME) BENT, FOOT SUPPORT
69 2 WASHER FLAT 1/2 ZINC
70 4 SCREW HHTT M8-1.25 x 20
71 1 FUEL TANK ASSY 8.0 GAL
72 1 FUEL CAP-VENTED
75 1 BEARING CARRIER REAR
76 1 STATOR 8KW
77 1
(CASTING) ENGINE ADAPTER
HOUSING
78 I ROTOR ASSEMBLY, 8kW
79 I CAPACITOR
80 I CLAMP
81 5 WASHER LOCK M8-5/16
82 4 SCREW IHHC M8-1.25 x 140 G8.8
83 1 WASHER FLAT 5/16-M8 ZINC
84 1 SCREW IHHC 5/16-24 x 8-1/2 G5
85 1 COVER ALTERNATOR INLET
86 1 GROMMET WIRE SLEEVE
87 2 SCREW PPHM M4-0,7 x 10
88 4 WASHER FLAT #10 ZINC
89 4 WASHER LOCK #10
90 4 SCREW PPHM M5-0,8 x 30
91 1 SCREW HHTT M6-1.0 x 12
92 1
ALTERNATOR FAN VARIED BLADE
SPACING
