PowerBoss 5,500 Watt Storm-Plus Generator
17
PARTS LIST – MAIN UNIT
Item Part # Qty Description
1 B189444GS 1 CRADLE
2 70642GS 4 MOUNT,Vibration
3 76222GS 3 SCREW
4 190220GS 1 HOUSING, Engine Adapter
8 96796GS 1 WASHER
9 189186GS 1 DECAL, Cover,Air Cleaner
10 190274BGS 4 SCREW
11 187365FGS 1 SCREW
14 189009GS 1 BRACKET, Muffler
15 188551GS 1 GASKET, Exhaust
16 66476GS 2 SCREW, w/Lock Washer
17 189008GS 1 MUFFLER
18 60706GS 2 SCREW
19 83083GS 1 SCREEN, Spark Arrest
21 67989GS 11 NUT
22 20566GS 1 DECAL, 1-800 #
24 J189011GS 1 SHIELD, Heat
26 74908GS 4 SCREW
31 77816GS 1 DECAL, Hot Muffler
34 186347GS 1 COVER, Bearing Carrier
35 23762GS 1 WASHER
36 86494GS 1 SCREW,Wing
37 B2153GS 4 SCREW
39 188973GS 4 GROMMET,Tank
40 78831CGS 4 SCREW
41 80270GS 1 VALVE,Tank
42 78299GS 1 BUSHING, Plastic Tank
43 85134GS 1 CAP, Fuel Gauge
44 189022GS 1 ASSY,Tank, Fuel
(Includes Items 41 & 42)
Item Part # Qty Description
45 189235GS 1 DECAL, Start Instructions
46 22097GS 4 WASHER, Lock
47 22127GS 4 NUT
48 14353621GS 1 WIRE, Ground
49 26850GS 2 WASHER
50 B4986GS 1 DECAL, Ground, Green
51 92982GS 1 DECAL, Danger
52 189153GS 1 DECAL, Quick Ref.
54 BB3061GS 1 BOTTLE, Oil
55 187330GS 1 HOOD, Rocker Arm Cover
56 189025GS 1 DECAL, Panel, Side
57 188333GS 1 DECAL, Gas Fill
58 190355GS 1 ASSY, Control Panel (see page 19)
59 189164GS 4 NUT
60 275092 1 MANUAL, Engine
61 189439GS 1 MANUAL, Owners
62 73054GS 1 DECAL, Shut-Off, Fuel
63 43438GS 1 PLUG, 250V, 30A
66 45771GS 4 NUT
67 43107GS 4 SCREW
68 22129GS 6 WASHER, Lock
69 190442GS 1 ASSY,Alternator (see page 20)
70 189826GS 1 HOSE, Fuel, Formed
71 48031CGS 2 CLAMP, Hose, Band
72 70644GS 2 SCREW
73 86292GS 1 SCREW
900 NSP 1 ENGINE
To Next Page
