Generac Portable Products PP5000T Generator
17
EXPLODED VIEW GENERATOR
Item Part # Qty. Description
1 NSP 1 ENGINE
2 66825B 1 CARRIER, Rear Bearing
3 91825 1 ASSEMBLY, Brush & Bridge
Rectifier
4 66365D 1 ADAPTER, Housing
6 86307 4 SCREW, Hex Hd 5/16-24 x
3/4 Sems
7 74716J 1 ASSEMBLY, Rotor
8 65791 1 BEARING
9 96796 1 WASHER, Special
10 75431 1 BOLT, Rotor
11 B91859J 1 ASSEMBLY, Stator
12 81917 1 PIN, Roll M4 x 10
13 86308C 4 BOLT, Stator
14 22769 1 WASHER, Shakeproof Int #10
15 B4225 1 DECAL, PP5000T
16 70642 2 MOUNT, Vibration - 45°
17 B4871 1 COVER, Bearing Carrier
18 52858 6 LOCK NUT, M8-1.25 Flange
19 76222 2 PPHMS, M8-1.25 x 40 mm
20 14353621 1 WIRE, Ground
21 82881 3 WASHER, Internal Lock
22 86292 1 SCREW, #10 Self Drilling x
3/4"
23 38150 6 WASHER, #8 Flat
24 23365 6 WASHER, Lock Serrated #8
25 68740 1 FILTER, Fuel
26 B84324 1 SHIELD, Heat
27 92982 1 DECAL, Danger
28 77374 1 TANK, Gas Plastic 5 Gal.
29 93826 1 DECAL, Operating
Instructions
30 78831B 4 CAPSCW., Hex Hd. M6 x 60
Item Part # Qty. Description
31 94834 1 CAP, with Fuel Gauge
32 77395 4 NUT, Hex Lock - M6
33 78299 1 BUSHING, Plastic Tank
34 80270 1 VALVE, Plastic Tank
35 81897 1 PANEL, Control
36 81919 1 PANEL, Control Back Plastic
37 68868 1 OUTLET,120 Volt 30 Amp
Locking
38 68867 1 OUTLET, 120/240 Locking
39 68759 1 OUTLET, 120 Volt 20 Amp
Duplex
40 84242 2 GROMMET, Rubber
41 67989 2 NUT, M8 Flange Serrated
42 74908 4 SCREW, Hex M5 - 0.80 x 10
43 22264 6 WASHER, #8 Lock
44 51715 6 NUT, Hex - M4 - 0.7
45 75207A 1 CIRCUIT BREAKER - 30 Amp
46 75207 2 CIRCUIT BREAKER - 20 Amp
47 26850 2 WASHER, Shakeproof 1/4"
48 75475 6 SCREW, M4 - 0.7 x 10 Pan
Head
49 85652 2 MOUNT, Rubber
50 82308 6 SCREW, Self Tapping
51 86494 1 SCREW, M6 x 16 Wing
52 B4986 1 DECAL, Ground
53 AB2265 1 CRADLE
54 67022 1 GROMMET, Rubber
57 66849 2 SCREW, M5 - 0.8 x 15
59 22695 1 6-PIN CONNECTOR, Male
60 22694 1 6-PIN CONNECTOR
63 83465 4 GROMMET, Mounting Tank
64 48031C 3 CLAMP, Hose - 1/4"
65 B2153 4 SCREW, Self Driller #12-14 x
7/8"
To Next Page
