ENGINE 3.0L G3 LS (RWD) MAKE
2 0F8425 1 ADAPTER ENGINE
3 0F9965C 1 FLEX PLATE 2 POLE
4 0F8931 1 SPACER FLEX PLATE
5 0G7461 1 STARTER MOTOR 12V
6 049821 3 SCREW SHC M8-1.25 X 30 G12.9
7 022129 17 WASHER LOCK M8-5/16
8 022145 13 WASHER FLAT 5/16-M8 ZINC
9 025507 5 WASHER SHAKEPROOF EXT 7/16 STL
10 064416 7 SCREW HHC M10-1.5 X 45 G8.8 FT
11 052243 1 SCREW HHC M10-1.5 X 60 G8.8
12 022131 9 WASHER FLAT 3/8-M10 ZINC
13 0D5417 8 SCREW HHC M10-1.0 X 25 G10.9
14 0F3844 8 WASHER FLAT .45 X 1.00
15 046526 5 WASHER LOCK M10
16 045772 4 NUT HEX M10-1.5 G8 YEL CHR
17 043107 5 SCREW HHC M8-1.25 X 25 G8.8
18 0G3638 1 ADAPTER OIL FILTER 3.0L
19 0D5419 1 OIL FILTER
20 055476 1 BSHG RDCR HEX 3/8 TO 1/8 GALV
21 0A8584 1 SWITCH OIL PRESSURE 10 PSI 2 POL
22 0G3775 1 DIP STICK OIL 3.0L
23 0G0100 2 (REF) GASKET EXHAUST
24 0F8795A 1 MANIFOLD EXHAUST LH
25 067989 12 NUT HEX FL WHIZ M8-1.25
26 0E7202AAS0R 2 HEAT SHIELD EXHAUST 3.0L
27 0F5966A 2 REFLECTIVE HEAT SHIELD 3.0L
28 022985 6 WASHER FLAT #6 ZINC
29 033472 6 RIVET POP .125 X .400 AL
30 085296 6 SCREW HHC 1/4-20 X 1/2 SS
31 083896 6 WASHER LOCK 1/4-M6 SS
32 084929 6 WASHER FLAT 1/4 SS
33 0F97650202 1 OIL FILLER CAP 3.0L
34 0F5114 1 DECAL REFER TO OWNERS MANUAL
35 0G33090ST03 1 BRACKET COIL
36 049226 6 WASHER LOCK M5
37 051716 3 NUT HEX M5-0.8 G8 CLEAR ZINC
38 055440 3 SCREW HHC M5-0.8 X 25 G8.8
39 0G4262 2 MANIFOLD INTAKE LOWER REWORK
40 0E0992A 6 PLUG EXPANSION 14 OD
41 0F9223 6 GASKET INTAKE MANIFOLD LWR G3
42 083601 4 SCREW HHC M6-1.0 X 80 C8.8
43 022473 13 WASHER FLAT 1/4-M6 ZINC
44 0C7125 4 SCREW HHC M6-1.0 X 120 C8.8
48 0G0607 1 ASSEMBLY HOSE PCV VALVE
49 0F9564 1 (REF) GASKET INTAKE ADAPTER
50 0F9563 1(REF) GASKET IDLE AIR CONTRL ACT CVR
51 0E6585 1 COVER IAC ACTUATOR
52 022097 4 WASHER LOCK M6-1/4
53 047411 2 SCREW HHC M6-1.0 X 16 G8.8
54 0F7695 1 EGR GASKET
55 0F6658 1 COVER EGR
56 039253 2 SCREW HHC M8-1.25 X 20 G8.8
57 0D3973 1 PLUG, EXPANSION 16MM
58 0G3720A 1 REWORK HARMONIC BAL 3.0L RWD
59 0D3488E 1 BELT SERPENTINE 71.04"
60 0G3643 1(REF) WATER PUMP 3.0L
61 0G3791A 1 HOSE WATER PUMP 3.0L
62 099502 2 CLAMP HOSE #24 B1.06-2.00
63 0G7856A 1 REWORK BREATHER TUBE 3.0L G3 LS
64 052265 3 SCREW HHC M8-1.25 X 65 G8.8
65 0D8028 2 PULLEY GROOVED ENGINE IDLER
66 0G3842 1 SPACER IDLER PULLEY 3.0L
67 042568 1 SCREW HHC M6-1.0 X 20 G8.8
68 0G3644 1(REF) SENSOR CRANKSHAFT SPEED 3.0L
69 0G38040ST03 1 WELDMENT IDLER BRACKET 3.0L
70 0D8025 1 BOLT HEX FL HD M8-1.25 X 28
71 0G3896 1 SPACER .34 X 1.00 X .11 STL/ZC
72 039414 1 SCREW HHC M8-1.25 X 35 G8.8
73 0D34540186 6 SPARK PLUG (PLATINUM) .044 GAP
74 027482 1 WASHER SHAKEPROOF EXT 5/16 STL
75 0G3909 1 HARN ENG 3.0L G14 R-200 2P (NOT SHOWN)
76 045771 2 NUT HEX M8-1.25 G8 CLEAR ZINC
77 0G35770ST03 1 BRACKET DC ALTERNATOR LOWER
78 0G38210ST03 1 BRACKET TENSIONER
79 0E9868A 1 ALTERNATOR DC W/OUT PULLEY
80 0F3217 1 SPACER DC ALTERNATOR PULLEY
81 0F3216C 1 PULLEY 132 OD DC ALTERNATOR
82 049814 1 SCREW HHC M10-1.5 X 25 G8.8
83 0G34700ST03 1 BRACKET THERMOSTAT 3.0L
84 049813 1 NUT HEX M6 X 1.0 G8 YEL CHR
85 035685 2 CLAMP HOSE #28 1.32-2.25
86 0F9232 1 HOSE UPPR RAD REAR
87 0A2711A 2 ADAPTER THERMOSTAT
88 048665 2 GASKET THERMOSTAT
89 0F9252 1 MACHINING,THERMOSTAT ADPTR
90 075885 1 THERMOSTAT 195 DEG
91 0A6751 1 SWITCH HI-TEMP 245D X 3/8 NPT
92 049226 1 WASHER LOCK M5
93 074908 1 SCREW HHTT M5-0.8 X 10 BP
94 052207 2 SCREW HHC M8-1.25 X 80 G8.8
95 047527 1 BARBED STR 1/2NPT X 3/4
96 057823 3 CLAMP HOSE #10 .56-1.06
97 050968 1 HOSE COOL 3/4 ID 20R3 (22” LG)
98 069860C 1 HOSE OIL DRAIN ASSY 21"
99 0C7649 1 CLAMP HOSE .38-.87
100 043790 1 BARBED EL 90 3/8 NPT X 3/8
101 077456 1 ADAPTER M12-1.75 X 3/8 NPT
102 052677 1 WASHER NYLON .50 X .87 X .06
103 049541 1 SCREW HHC M10-1.5 X 35 G8.8
104 0G3781 3 RETAINER SPARK PLUG WIRE
105 0G4431 1 RESTRICTOR PCV
106 0G3245 1 SPARK PLUG WIRE SET
107 0F9228 1 COIL IGNITION
108 031919 1 PLUG STD PIPE 3/8 COUNTERSUNK
109 0F8795 1 MANIFOLD EXHAUST RH
110 051751 4 (REF) SCREW HHC M6-1.0 X 50 G8.8 (INCL. WITH I/N 47)
111 0F9224 6(REF) GASKET INTAKE MANIFOLD UP G3
112 0G5971 1 RESTRICTOR COOLANT BYPASS
113 026850 1 WASHER SHAKEPROOF EXT 1/4 STL
114 0G8084 1 COOLANT X-OVER CASTING
115 038750 2 SCREW HHC M6-1.0 X 30 C8.8
