(2) 1 0F5859 1 REAR WRAP C4
(2) 2 0F5855 2 DOOR C4
(2) 3 0F5858 2 DISCHARGE DUCT LH & RH SIDE C4
(2) 4 0F5856 2 FRONT CORNERS C4
(2) 5 0F5857 1 DISCHARGE CENTER DUCT C4
(3) 6 0F5854 1 ROOF C4 ALUM
11 0F8869D 1 KEY VISE-ACTION LATCH SLOT CIR
12 0C2454 75 SCREW THF M6-1 X 16 N WA Z/JS
(1) 13 077992 21 NUT HEX LOCK M6-1.0 SS NY INS
14 087233 2 RIVET POP .1875 X .450 SS
15 0E3257 4 SCREW HWHTF M6-1.0 X 16
16 049813 2 NUT HEX M6 X 1.0 G8 YEL CHR
17 022447 2 WASHER SHAKEPROOF INT 1/4
18 0912970094 2 ASSY WIRE 14AWG 34.8" GRN/YEL
19 0F2835 1 (REF.) INNER DISCHARGE DUCT, C4
20 042568 2 SCREW HHC M6-1.0 X 20 G8.8
21 0F2786 3 SPLITTER C4
22 0F2785 1 SPLITTER LOWER C4
23 0F3185 1 STRINGER SPLITTER C3
24 0F2787 2 SUPPORT SLITTER C4
25 0F3890B 8 RETAINER INSULATION (820)
26 0C2634A 1 ASSEMBLY COVER ACCESS
27 022473 3 WASHER FLAT 1/4-M6 ZINC
28 022097 1 WASHER LOCK M6-1/4
29 022127 1 NUT HEX 1/4-20 STEEL
30 0F3072 10 INSULATION RETAINMENT HANGER
31 078115 46 WASHER SELF LOCKING DOME #4-40
32 0F3760K 3 INSULATION SPLITTER
33 0F3760E 3 INSULATION LOWER SPLITTER
34 0F5048D 4 VISE-ACTION LATCH SLOTTED CIR
35 0E5968 1 GASKET EXTRUDED TRIM (374.64” LG)
36 0F3760J 1 INSULATION DISCHARGE FRONT
37 0F3890A 9 RETAINER INSULATION (740)
38 0F3890 6 RETAINER INSULATION (450)
39 0F3760H 1 INSULATION DISCHARGE TOP
40 0F3760F 1 INSULATION ROOF TOP
41 0F5049 4 TAB PULL
42 0F3760L 1 INSULATION LOWER SPLITTER
43 0F3760C 2 INSULATION DOOR
44 0F3760A 1 INSULATION REAR WRAP
45 0F3760 2 INSULATION CORNER POST
46 0F3760D 2 INSULATION DISCHARGE SIDE
47 078115A 10 WASHER SELF LOCKING DOME #8-32
48 066760 1 STRIP SEALANT 1/8 X 1 (44.52”LG)
(2) NOTE: PART NUMBER SHOWN IS FOR TAN / STEEL. REFER TO THE SAMPLE
GUIDE BELOW FOR AVAILABLE COLOR AND/OR ALUMINUM PART NUMBER FORMAT.
0FXXXX0ST01 = TAN / STEEL 0FXXXX0ST13 = BISQUE / STEEL
0FXXXX0AL01 = TAN / ALUMINUM 0FXXXXALT13 = BISQUE / ALUMINUM
0FXXXX0ST08 = T- GRAY / STEEL 0FXXXX0ST14 = GRAY / STEEL
0FXXXX0AL08 = T- GRAY / ALUMINUM 0FXXXXALT14 = GRAY / ALUMINUM
0FXXXX0ST05 = WHITE / STEEL
0FXXXX0AL05 = WHITE / ALUMINUM
(3) PART NUMBER SHOWN IS FOR TAN. SEE GUIDE BELOW FOR AVAILABLE COLOR AND PART NUMBER
FORMAT.
0FXXXX0AL08 = T- GRAY / ALUMINUM 0FXXXXALT13 = BISQUE / ALUMINUM
0FXXXX0AL05 = WHITE / ALUMINUM 0FXXXXALT14 = GRAY / ALUMINUM
