Generac Power Systems SD100 User Manual

STANDBY PRIME
SD100 SD100
GENERATOR OUTPUT VOLTAGE/KW-60Hz Rated AMP Rated AMP
120/240V, 1-phase, 1.0 pf 100 417 91 379
120/208V, 3-phase, 0.8 pf 100 347 91 316
120/240V, 3-phase, 0.8 pf 100 301 91 274
277/480V, 3-phase, 0.8 pf 100 150 91 137
600V, 3-phase, 0.8 pf 100 120 91 109
MOTOR STARTING KVA
Maximum at 35% instantaneous voltage dip 208/240/416V 480V 208/240/416V 480V
with standard alternator; 60 Hz 206 275 206 275
FUEL
Fuel consumption—60 Hz Load 25% 50% 75% 100% 25% 50% 75% 100%
gal./hr. 2.3 4.3 5.9 7.7 1.9 3.5 5.1 6.3
liters/hr. 8.7 16.2 22.4 29.0 7.1 13.3 19.4 23.9
Fuel consumption—50 Hz gal./hr. 1.8 3.4 4.7 6.1 1.5 2.8 4.1 5.0
liters/hr. 7.0 12.9 17.9 23.2 5.7 10.6 15.5 19.1
Fuel pump lift 36" 36"
COOLING
Coolant capacity System - US gal. (lit.) 5.5 (20.8) 5.5 (20.8)
Engine - US gal. (lit.) 3.75 (14.2) 3.75 (14.2)
Coolant flow/min. 60 Hz - US gal. 38 38
Heat rejection to coolant 60 Hz full load BTU/hr. 280,000 252,000
Inlet air* 60 Hz - cfm (m
3
/min.) 7500 (212.4) 7500 (212.4)
 Max.airtemperaturetoradiator* °C(°F) 60(140) 60(140)
 Max.operatingambienttemperature* °C(°F) 50(122) 50(122)
COMBUSTION AIR REQUIREMENTS
Flow at rated power 60 Hz - cfm ( m
3
/min.) 351 (10.0) 320 (9.1)
EXHAUST
Exhaust flow at rated output 60 Hz - cfm ( m
3
/min.) 988 (28.0) 880 (24.9)
Max recommended back pressure Inches Hg 1.5 1.5
 Exhausttemperature60Hz(fullload) °F(°C) 1050(566) 990(532)
Exhaust outlet size 4.0" O.D. 4.0" O.D.
ENGINE
Rated RPM 60 Hz 1800 / 1500 1800
HP at rated KW 60 Hz 158 / 122 144 / 99
Piston speed 60 Hz - ft./min. (m/min.) 1500 (457) 1500 (457)
BMEP 60 Hz / psi 248 225
DERATION FACTORS
Temperature
-4.1% for every 10
o
Cabove-°C 40 40  
-2.3% for every 10
o
Fabove-°F 104 104
Altitude
-0.8% for every 100 m above - m 1067 1067
-2.5% for every 1000 ft. above - ft. 3500 3500
OPERATING DATA
NOTE: Consult your
Generac dealer for
additional voltages.
SD100
* Note: Values given are maximum temperatures to which power adjustments can be applied. Consult your Generac
Power Systems representative if operating conditions exceed these maximums.
