General Pump MSS Series - Page 17

GENERAL PUMP
A member of the Interpump Group
MSS SERIES
Page 17
REPAIR KITS
Item MSS36 MSS40 MSS45 MSS50 MSS55
66-68-91-92-96-97-99-100 F1134 F1135 F1136 F1137 F1138
37-74-75-80-81 F1139
2-13-14-17-22-28-32-34-35-37-40-4246-49-54
57-60-62-63-66-68-74-75-80-81-86-91-92
96-97-99-100
F1140 F1141 F1142 F1143 F1144
Item Part # Description Qty.
1 F
060100240
G
ear box housing
1
F060100460 Gear box housing, 2200 RPM 1
2 F
872047005
W
asher Ø 10
8
3 F
871125108
S
crew M 10 x 40
8
4 F052000100 Gear 1500 RPM 1
F052000120 Gear 1800 RPM 1
F
052000280
G
ear 2200 RPM
1
5 F030000090 Gear retainer flange 1
6 F871125105 Screw M 10 x 25 3
7 F872126004 Retainer pin Ø 12 x 40 2
8 F871125110 Screw M 10 x 50 7
9 F010100100 Hydraulic motor flange 1
10 F871125154 Screw M 10 x 30 8-14-16
11 F871125153 Screw M 10 x 25 3
12 F063100190 Gear box flange 1
13 F881010131 O-ring Ø 113.97 x 2.62 1
14 F881080026 Oil seal Ø 55 x 75 x 10 1
15 F811110010 Bearing 1
16 F063100150 Gear box cover 1
17 F080600140 Gear box gasket 1
18 F872097009 Pinion key 1
F872097013 Pinion key (pinion Ø 48) 1
19 F052000110 Pinion 1500 RPM (Z27) 1
F052000131 Pinion 1800 RPM (Z24) 1
F052000180 Pinion 1500 RPM (Z27) Ø 48 1
F052000210 Pinion 1800 RPM (Z24) Ø 48 1
F052000270 Pinion 2200 RPM (Z22) 1
F052000300 Pinion 2200 RPM (Z22) Ø 48 1
20 F811110002 Bearing 1
21 F812000001 Brass bearing 3
22 F872046006 Washer Ø 12 6
23 F035000070 Connecting rod screw 8
26 F871115152 Screw M 6 x 14 16
27 F040000070 Lower cover 1
28 F080600130 Lower cover gasket 1
29 F060100220 Crankcase 1
30 F034000010 Pin 1
31 F811110016 Bearing 1
32 F881080032 Oil seal Ø 70 x 90 x 10 1
33 F063400640 Bearing cover (direct drive version) 1
34 F881080031 Oil seal 65 x 90 x 10 1
35 F080600110 Bearing cover gasket 2
36 F801057002 Magnetic plug G 1/2” 1
37 F872043002 Aluminum washer 1/2” 4
38 F063400540 Back cover 1
39 F871121152 Screw M 8 x 20 6
40 F080600100 Back cover gasket 1
41 F001000010 Oil dipstick 2
42 F872041501 Washer Ø 3/8” 2
43 F872026003 Eyebolt M 16 2
44 F030000030 Eyebolt spacer 2-4
45 F801054027 Filling plug G 1” 1
46 F881010116 O-ring Ø 29.82 x 2.62 1
47 F801056002 Venting plug G 1/2” 1
48 F040000050 Upper cover 1
49 F080600120 Upper cover gasket 1
50 F872100005 Crankshaft key 1
51 F050000100 Crankshaft 1
52 F811111008 Bearing 1
53 F811920004 Bearing bushing 1
54 F872069012 Washer MB 12 1
55 F872020012 Ring nut KM 12 1
56 F063400580 Bearing cover 1
57 F801077003 Greaser M 10 x 1 3
58 F250000020 Connecting rod assembly 3
59 F250001060 Plunger assembly 3
60 F872142015 Retainer pin Ø 5 x 36 3
61 F071000060 Wrist pin Ø 28 3
62 F881081000 Oil seal Ø 32 x 45 x 6.2 Spec. 3
63 F881010127 O-ring Ø 64.77 x 2.62 3
64 F063400560 Oil seal plunger cover 3
65 F205000000 Wiper 3
66 F881012115 O-ring Ø 26.65 x 2.62 3
I
tem
P
art #
D
escription
Q
ty.
67 F024200340 Plunger MSS36 3
F024200350 Plunger MSS40 3
F
024200360
P
lunger MSS45
3
F024200370 Plunger MSS50 3
F024200380 Plunger MSS55 3
6
8
F
872040004
W
asher Ø 10 Spec.
3
69 F871135516 Screw M 14 x 120 inox MSS36-40-45 3
F871135510 Screw M 14 x 80 inox MSS50-55 3
7
0
F
208005040
V
alve assembly
3
71 F871245358 Screw M 10 x 25 6
72 F871135153 Screw M 14 x 45 12
73 F063100110 Valve cover 3
74 F881112002 Antiextrusion ring 3
75 F881010219 O-ring Ø 65.09 x 3.53 Spec. 3
76 F021300110 Delivery valve guide 3
77 F090200090 Delivery valve spring 3
78 F082200110 Delivery valve poppet 3
79 F081200130 Delivery valve seat 3
80 F881011166 O-ring Ø 66 x 3 Spec. 3
81 F881011159 O-ring Ø 50 x 3 Spec. 6
82 F021300090 Suction valve guide 3
83 F090200080 Suction valve spring 3
84 F082200010 Suction valne poppet 3
85 F081200120 Suction valve seat 3
86 F872041300 Copper washer Ø 1/4” 8
87 680115 Plug G 1/4” 8
88 F871145120 Screw M 18 x 180 8
89 F064100340 Manifold 3
90 F084000010 Plug G 1/2” nickel 3
91 F881011052 O-ring Ø 78 x 2 9
92 F881011164 O-ring Ø 62 x 3 Spec. 3
93 F062200220 Cylinder MSS36-40 3
F062200230 Cylinder MSS45 3
F062200240 Cylinder MSS50 3
F062200250 Cylinder MSS55 3
94 F031300020 Spacer ring MSS36-40 3
F031300120 Spacer ring MSS45 3
F031300050 Spacer ring MSS50 3
F031300060 Spacer ring MSS55 3
95 F031200090 Packing ring MSS36 3
F031200100 Packing ring MSS40 3
F031200110 Packing ring MSS45 3
F031200210 Packing ring MSS50 3
F031200220 Packing ring MSS55 3
96 F881020010 Pressure packing MSS36 6
F881020011 Pressure packing MSS40 6
F881020012 Pressure packing MSS45 6
F881020014 Pressure packing MSS50 3
F881020015 Pressure packing MSS55 6
97 F881011161 O-ring Ø 56 x 3 MSS36-40 3
F881011163 O-ring Ø 59.5 x 3 MSS45 3
F881011165 O-ring Ø 65 x 3 MSS50 3
F881011167 O-ring 69.5 x 3 MSS55 3
98 F022300340 Packing support MSS36 3
F022300350 Packing support MSS40 3
F022300360 Packing support MSS45 3
F022300370 Packing support MSS50 3
F022300380 Packing support MSS55 3
99 F881010127 O-ring Ø 64.77 x 2.62 MSS36-40-45-50 3
F881010014 O-ring Ø 66.40 x 1.78 MSS55 3
100 F881061014 Scraper MSS36 3
F881061015 Scraper MSS40 3
F881061017 Scraper MSS45 3
F881061018 Scraper MSS50 3
F881061019 Scraper MSS55 3
102 F052000290 Pinion 1800 RPM (Z24) 1
F052000320 Pinion 1500 RPM (Z27) 1
103 F811110014 Bearing 1
104 F063100210 Hydraulic motor flange 1
