Notes
15
PARTS LIST
10-110 & 10-110CF
NO PART N0. DESCRIPTION SPECIFICATION QTY
1 10110-01 CASTER 4
2 10110-02 HEX. HEAD BOLT 5/16” X 1/2” L 40
4A 10110-04A BASE PLATE 1
5 10110-05 PAN HEAD SCREW 3/16” X 3/8” L 12
6A 10110-06A INLET COVER 1
7A 10110-07A CAP SCREW M6 X 1.0 X 30 MM L.H. 1
9 10110-09 WASHER 1
10A 10110-10A FAN 1
11A 10110-11A COLLECTOR BODY 1
12 10110-12 WASHER 5/16” 8
13 10110-13 PAN HEAD SCREW 3/16” X 3/8” L 1
14 10110-14 HEX. HEAD BOLT 5/16” X 3/4” L 2
15 10110-15 HEX. HEAD BOLT 5/16” X 1” L 4
16 10110-16 SWITCH 1
17A 10110-17A MOTOR 1
18 10110-18 NUT 5/16” 4
19 10110-19 CONNECTOR 1
22 10110-22 COLLECTOR BAG (ITEM #10-120) 1
23 10110-23 VERTICAL SUPPORT ROD 1
24 10110-24 DRUM 1
25 10110-25 GASKET 1
26A 10110-26A HANGER* 1
27 10110-27 FILTER** 1
28 10110-28 FOAM GASKET 2
29 10110-29 HOSE INLET (“Y” FITTING) 1
29A 10110-29A CAP 1
30 10110-30 KEY 7MM X 7MM X 30MM 1
31 10110-31 POWER CORD 1
32 10110-32 OPEN END WRENCH 12MM 1
33 10110-33 HEX. WRENCH 5MM 1
34 10110-34 BELT CLAMP* (ITEM #10-093) 2
35 10110-35 FOAM GASKET 1
36 10110-36 LOCK WASHER 1/4” 1
*Not supplied/required for Model #10-110CF
IMPORTANT: When ordering replacement parts, always give the model number, serial number of the
machine and part number. Also a brief description of each item and quantity desired.
**Filter bag #10-115 for model 10-110 or Canister filter #10-106C for model 10-110CF.
