16
PARTS LIST
10-106C
Canister supplied
on Model 10-110CF
PART # DESCRIPTION SPEC. QTY
10106C-25 CANISTER FILTER DIA.500MM 1
10106C-26 NUT 5/16” 1
10106C-27 SET SCREW 5/16”X3/4” 1
10106C-28 HANDLE 1
10106C-29 HANDLE SPONGE 7/8” 1
10106C-30 CAP 3/4” 1
10106C-31 CANISTER FIXING PLATE 2
10106C-32 BEARING 1206 2
10106C-35 FLAPPER 3
10106C-36 SPINDLE 1
PART # DESCRIPTION SPEC. QTY
10106C-38 ROUND HEAD SCREW M5X6 6
10106C-39 FIXING PLATE 2
10106C-40 BOTTOM FIXING PLATE 1
10106C-41 PHILLIPS HEAD SCREW M5X15 4
10106C-42 FOAM GASKET 3X20X1560 1
10106C-43 FOAM GASKET 5X42X1565 1
10106C-44 BELT CLAMP 500CK 1
10106C-58 FLANGE BOLT M5X12 8
10106C-59 NUT M5 6
10106C-60 FLAPPER BRACKET 1
