General 240 - Page 35

240 ONE MAN HOLE DIGGER, FORM GOM26010601, VERSION 2.0, AUTHORIZATION: DVR, PAGE: 33
REFERENCE
NUMBER
PART
NUMBER
DESCRIPTION QTY APPLICATION
1
2
3
4
5
6
7
8
9
P801
P302
20051000
20051200
52040000
15040700
2121
AP-21-S
233-5092
Bit, Screw
Bit, Screw
Pin, Roll, 5/16” x 1-1/4”, Plain Finish
Pin, Roll, 5/16” x 1-1/2”, Plain Finish
Nut, Hex, 1/4” UNC, Two Way, Plated
Screw, Cap, 1/4” x 7/8” UNC, Plated
Pin, Auger (Includes P/N AP-21-S)
Pin, Safety
Decal, Danger
1
1
1
1
2
2
1
1
1
2135-2E Auger
2135-4E thru
2135-8E Augers
2135-3E Auger
2135-2E and
2135-3E Augers
2135-4E thru
2135-8E Augers
2135-4E thru
2135-8E Augers
2135-4E thru
2135-8E Augers
All Augers and
2135-15X Extension
All Augers and
2135-15X Extension
All Augers and
2135-15X Extension
Replacement Parts Diagrams
2135 Series Earth Augers
1” Diameter Round Drive Connection
For Use With 210/240 Series Hole Diggers
