28 Drain Pan Assy
29 Bell Mouth
30 Terminal Wire Cover
-- Drain Hose
31 Drain Cap
2012.03.16
INDOOR UNIT
9378207011
9378227019
9378548015
9379665001
9375502010
28
30
31
29
21 Sensor Holder
22 Float Switch
24 Drain Pump Holder B
25 Pump Rubber
26 Drain Hose
27 Drain Port
9378329010
9900465018
23 Pump Assy 9900464011
9375518011
9378426016
9378212015
9378213012
Ref. Description Part number
23
22
21
27
26
25
24
24
