14
15
12
16
11
13
INDOOR UNIT
Evaporator
12
11 Evaporator Assy (09) 9316922013
12 Joint Pipe Assy (09) 9316923010
11 Evaporator Assy (12) 9317268011
12 Joint Pipe Assy (12) 9317190015
13 Filter Guide 9316578005
15
14
Evaporator Holder R 9316565005
16 Evaporator Holder L 9316564008
Rear Bracket 9316566002
Ref. Description Part number
2008.01.31
