OUTDOOR UNIT
1 Top Panel Assy 9309230057
2 Top Panel Seal 9309228016
3 Cabinet Assy 9314809040
4 Blow Down Grille 9308884015
5 Cabinet Right Assy 9309236011
6 Fan Ring 9308885012
7 Grip 9308880017
8 Switch Cover 9308882028
9 Protective Net 9315319012
10 4-Way Valve Assy 9315726018
11 Expansion Valve Assy 9311641018
13 Condenser 9311381037
14 Thermistor Spring-A 313728262708
15 Thermistor Spring 9300089012
16 Propeller Fan 9309909014
17 Nut 9304902003
18 Motor Bracket 9308872012
19 Separator Assy 9312971015
20 Base Assy, Painted 9308869081
21 3-Way Valve Assy 9315159014
22 2-Way Valve Assy 9313064013
24 Cord Clamp 9307271014
25 Terminal 9306489038
26 Inverter PCB Assy 9707039030
29 Fuse 0600382018
32 Expansion Valve Coil 9900057039
34 Fan Motor 9601725015
35 Compressor Assy 9313764012
36 Emblem 9315211019
Outdoor Temp. Thermistor
39 Solenoid Coil 9970033018
--- IPM 9705720015
--- 9900210045
Thermistor Assy--- 9900148027
9309230057
9309228016
9314809040
9308884015
9309236011
9308885012
9308880017
9308882028
9315319012
9315726018
9311641018
9311381037
313728262708
9300089012
9309909014
9304902003
9308872012
9312971015
9308869081
9315159014
9313064013
9307271014
9306489038
9707039023
0600382018
9900057039
9601725015
9313764012
9315211019
9970033018
9705720015
9900210045
9900148027
Ref.
No.
Description
Part No.
AOHR14LCC AOHR18LCC
Ord.
Q'ty
