2005.02.28
13
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT
PARTS LIST
--- Indicator PCB Assy 9705039032
--- Evaporator B Assy 9311275022
1 Air Filter 9309997011
2
Filter (Electric) 9312153015
3 Filter (ION) 9311925033
5
4
Clamper (Grille) 9306755010
6 Front Panel Total Assy 9313130183
7
Intake Grille Assy 9313131142
24 Crossflow Fan Assy 9307836015
37 Insulation (Pipe)-E 9304607007
38
Holder (Evaporator)-L 9309982017
39 Holder (Evaporator)-R 9309983014
40 Water Seal 9312912018
42 Air Seal 9310611005
46
Step Motor 9900139025
48 Fan Motor Assy 9601814016
51
Remote Control Unit 9315027030
52
Bracket Panel 9310001004
61-1 Flow Control Panel-U 9309991033
61-2
Flow Control Panel-Z 9309992030
188
Power Cord Assy 9900339012
236 Controller PCB Assy 9705656123
--- Pipe Temperature Thermistor 9702039042
---
Room Temperature Thermistor 9700801108
Holder (Filter) 9306602017
20 Gear-A 9309994003
21 Casing Assy 9311354079
23 Cover (Casing)-B 9314160011
26 Clamp (Motor) 9310102008
27 Shaft Holder-C Assy 9306628017
28 Drain Hose Assy 9314147012
29 Drain Cap Assy 9314493010
30
Wire Clamper 9311946014
31
Box (Switch) 9312908011
32 Cover (Switch) 9312909018
33 Evaporator Total Assy 9313099015
36
Joint Pipe Assy 9313792015
9705039032
9311275022
9309997011
9312153015
9311925033
9306755010
9313130183
9313131142
9307836015
9304607007
9309982017
9309983014
9312912018
9310611005
9900139025
9601814016
9315027030
9310001004
9309991033
9309992030
9900339012
9702039042
9700801108
9306602017
9309994003
9311354079
9314160011
9310102008
9306628017
9314147012
9314493010
9311946014
9312908011
9312909018
9313099015
9313792015
9705656116
(K02DR-0504HSE-C1) (K02DR-0505HSE-C1)
Ref.
No.
Description
Part No.
ASHA14LCC ASHA18LCC
Ord.
Q'ty
To Next Page
