General ASG17USBQ User Manual

12005.01.14
SPECIFICATIONS
INDOOR UNIT
ASG17FSBQ
ASG17FSCQ
ASG17USBQ
ASG17FSCQ
OUTDOOR UNIT
AOG17FNBK
AOG17FNBN
AOG17UNBK
AOG17UNBN
COOLING CAPACITY (kW)
4.70
4.70
HEATING CAPACITY (kW) - 5.40
COMPRESSOR
FAN MOTOR
DIMENSIONS
TYPE
Hermetic type, Permanent split condenser,
2 pole, Single phase, Induction motor, Rotary
DISCRIMINATION
5KS225DAC
DISCRIMINATION (INDOOR UNIT)
DISCRIMINATION (OUTDOOR UNIT)
INDOOR UNIT
OUTDOOR UNIT
INDOOR UNIT
OUTDOOR UNIT
MFA - 17AT
MFB - 24JTT
POWER SOURCE
230
HI-SPEED
1,300
FAN SPEED
FAN SPEED
MED-SPEED
1,210
780
LO-SPEED( r.p.m. )
( r.p.m. )
1,110
H x W x D (mm)
H x W x D (mm)
285 x 900 x 172
650 x 830 x 320
WEIGHT
GROSS / NET (kg)
GROSS / NET (kg)
13 / 10
51 / 47
56 / 52
POWER SOURCE (V) 230
FREQUENCY (Hz) 50
RUNNING CURRENT (A)
COOLING 8.3 7.9
HEATING - 8.9
INPUT WATTS (kW)
COOLING 1.85 1.76
HEATING - 1.99
E.E.R. (kW/kW)
COOLING 2.54 2.67
HEATING - 2.71
MOISTURE REMOVAL ( /hr) 2.1
AIR CIRCULATION-Hi (m
3
/hr) 560
ELECTRICAL DATA
Note : Between 7.5 m and 20 m, when using a connection pipe other than that in the table,
charge additional refrigerant with 0.53 oz (15 g) / 3.3 ft (1 m) as the criteria.
REFRIGERANT CHARGE (R410A)
FULL CHARGE
AMOUNT
25 ft ( 7.5 m )
33 ft ( 10 m )
49 ft ( 15 m )
66 ft ( 20 m )
29.5 oz ( 838 g )
28.2 oz ( 800 g )
45.4 oz ( 1,288 g )
44.1 oz ( 1,250 g )
32.2 oz ( 913 g )
34.8 oz ( 988 g )
48.1 oz ( 1,363 g )
50.7 oz ( 1,438 g )
Pipe Length
www.enindel.com

General ASG17USBQ Specifications

General

Brand	General
Model	ASG17USBQ
Category	Air Conditioner
Language	English
