Thermistor resistance values <Indoor unit side>
1) Room temperature thermistor (TH
IA
)
2) Indoor heat exchanger temperature thermistor (TH
HM
, TH
HI
)
Room
temperature 0 2.5 5 7.5 10 12.5 15 17.5 20 22.5 25 27.5 30
(°C)
Resistance
value 33.6 29.5 25.9 22.8 20.2 17.9 15.8 14.1 12.5 11.2 10.0 9.0 8.0
(kΩ)
Room
temperature 32.5 35 37.5 40 42.5 45 47.5 50
(°C)
Resistance
value 7.2 6.5 5.9 5.3 4.8 4.3 3.9 3.6
(kΩ)
Heat exchanger
temperature 0 2.5 5 7.5 10 12.5 15 17.5 20 22.5 25 27.5 30
(°C)
Resistance
value 176.0 153.5 134.2 117.6 103.3 91.0 80.3 71.0 62.9 55.9 49.7 44.3 39.6
(kΩ)
Heat exchanger
temperature 32.5 35 37.5 40 42.5 45 47.5 50 52.5 55 57.5 60
(°C)
Resistance
value 35.4 31.7 28.5 25.6 23.1 20.8 18.8 17.1 15.5 14.1 12.8 11.6
(kΩ)
