2 Fan Guard 9371187013 9371187013 9371187013 9371187013 9371187013 9371187013 9371187013
2 Fan Cover (Guard) ––––– ––––– ––––– ––––– ––––– ––––– 9359808015
4 Emblem (Rear) 9372171011 9372171011 9372171011 9372171011 9372171011 9372171011 313791088308
5 Front Panel Painted 9371924014 9371924014 9371924014 9371924014 9371924014 9371924014 9359797029
5-1 Cabinet-A Assy ––––– ––––– ––––– ––––– ––––– ––––– 9360268150
6 Side Panel R Painted 9371927015 9371927015 9371927015 9371927015 9371927015 9371927015 –––––
7 Cover (Switch) Assy 9389307410 9389307410 9358011010 9389307410 9389307410 9358011010 –––––
8 Wire Assy (Compressor) 9372334010 9372334010 9372334010 9372334010 9372334010 9372334010 9370945058
9 Cabinet-B Sub Assy ––––– ––––– ––––– ––––– ––––– ––––– 9360267016
10 Air Seal Plate 9372213018 9372213018 9372213018 9372213018 9372213018 9372213018 –––––
12 Base Assy, Painted 9371920016 9371920016 9371920016 9371920016 9371920016 9371920016 9359813019
13 Packed Valve (5/8) 9372650011 9372650011 9372650011 9372650011 9372650011 9372650011 9366193005
14 Packed Valve (3/8) 9372649015 9372649015 9372649015 9372649015 9372649015 9372649015 9362380003
14-1 Check Valve ––––– ––––– 9372198025 ––––– ––––– 9372198032 9372198025
15 Dryer 9368111014 9368111014 9368111014 9368111014 9368111014 9368111014 9368111014
16 Condenser Assy 9372181058 9372181065 9372181089 9372181072 9372181102 9372181119 9360280022
17 U Pipe-Y ––––– ––––– 313728127102 ––––– ––––– ––––– –––––
18 Inlet Pipe (Condenser) Assy ––––– ––––– ––––– ––––– ––––– ––––– 9369070006
18-1 Outlet Pipe (Condenser) Assy ––––– ––––– ––––– ––––– ––––– ––––– –––––
18-4 Suction Pipe ––––– ––––– ––––– ––––– ––––– ––––– 9372872024
20 Discharge Pipe ––––– ––––– ––––– ––––– ––––– ––––– 9369067006
21 H-Ins. Pipe-B ––––– ––––– 9361953000 ––––– ––––– 9361953000 –––––
26 Compressor Cover 9372327029 ––––– ––––– 9372327029 9372327029 ––––– 9371501017
26 Compressor Cover-A ––––– 9372327012 9372327012 ––––– 9372327012 9372327012 –––––
29 Separate Wall 9371933016 9371933016 9371933016 9371933016 9371933016 9371933016 9359804017
32 Control Box 9371935010 9371935010 9371935010 9371935010 9371935010 9371935010 –––––
32 Control Box Metal ––––– ––––– ––––– ––––– ––––– ––––– 9359839019
34 Capacitor (Fan Motor) 9703306051 9703306051 9703306051 9703306051 9703306051 9703306051 9703306051
35-4 Pressure Switch 9370941005 ––––– ––––– 9370941005 ––––– ––––– –––––
37 Running Capacitor 9704436023 9704436023 9704436023 9703107023 9703107023 9703107023 9703107023
38 Capacitor Clamp 9351770013 9351770013 9351770013 313791061807 313791061807 313791061807 9360610010
39 Propeller Fan Assy 9366378013 9366378013 9366378013 9366378013 9366378013 9366378013 –––––
39 Propeller Fan ––––– ––––– ––––– ––––– ––––– ––––– 9359837015
41 Fan Motor Assy-Out 9601671022 9601671022 9601671015 9601671022 9601671022 9601671015 9703306051
42 Rubber-B ––––– ––––– ––––– ––––– ––––– ––––– 9360775009
45-1 Motor Bracket 9371929019 9371929019 9371929019 9371929019 9371929019 9371929019 9369627002
45-2 Motor Bracket-Top 9371931012 9371931012 9371931012 9371931012 9371931012 9371931012 9369628009
45-3 Motor Bracket-Center 9371930015 9371930015 9371930015 9371930015 9371930015 9371930015 9373076018
45-4 Motor Bracket-Bottom 9371932019 9371932019 9371932019 9371932019 9371932019 9371932019 9369630002
46 Compressor Assy 9370878004 9370878004 9370878004 9371448015 9371448015 9371448015 9371505015
47-1 Rubber (Discharge Pipe) 313194159807 313194159807 ––––– 313194159807 313194159807 313194159807 313194159807
51 Special Nut M5 9300301015 9300301015 9300301015 9300301015 9300301015 9300301015 9371815015
54 Condensing Pipe Assy 9371378039 9371378046 ––––– 9371378053 9371378046 ––––– –––––
54-1 Condensing Pipe ––––– ––––– 9372194027 ––––– ––––– 9372194058 9369085000
54-2 Outlet Pipe-B ––––– ––––– ––––– ––––– ––––– ––––– 9370667004
55 Special Nut M8 9355091008 9355091008 9355091008 9355091008 9355091008 9355091008 9355091008
64 Side Panel L Painted 9371926018 9371926018 9371926018 9371926018 9371926018 9371926018 –––––
64 Cabinet-Left ––––– ––––– ––––– ––––– ––––– ––––– 9359840022
82-1 Check Joint ––––– ––––– ––––– ––––– ––––– ––––– 9360162007
83 Check Joint Bracket ––––– ––––– ––––– ––––– ––––– ––––– 9359807018
85 Valve Plate Painted 9371928012 9371928012 9371928012 9371928012 9371928012 9371928012 –––––
85 Valve Fixing Plate ––––– ––––– ––––– ––––– ––––– ––––– 9359806011
107 Rubber Seat-A (For Comp. ) 9351049010 9351049010 9351049010 9351049010 9351049010 9351049010 –––––
107 Rubber Mount ––––– ––––– ––––– ––––– ––––– ––––– 9362368001
109 Terminal Cover (Comp. ) 9371511016 9371511016 9371511016 9371511016 9371511016 9371511016 9371513010
111-1 Nut ––––– ––––– ––––– ––––– ––––– ––––– 0700193019
111-2 Washer ––––– ––––– ––––– ––––– ––––– ––––– 0700078026
115 Suction Pipe-A 9372176061 9372176061 9372176078 9372176023 9372176047 9372176023 –––––
115 Muffler ––––– ––––– 9372369012 ––––– ––––– 9372369012 –––––
115-1 Suction Pipe-B ––––– ––––– 9371275093 9371275116 ––––– 9371275093 –––––
115-2 Discharge Pipe-A 9372179024 9372179024 9372179017 9372179024 9372179024 9372179017 –––––
115-3 Discharge Pipe-B 9372180075 9372180075 9372180013 9372180082 9372180082 9372180020 –––––
146 Outlet Pipe (Cond. ) Assy ––––– ––––– ––––– ––––– ––––– 9372189038 –––––
146 Distributor Assy ––––– ––––– ––––– ––––– ––––– ––––– 9372867020
178-2 Capillary Holder Rubber 313414274807 313414274807 313414274807 313414274807 313414274807 313394274808 –––––
187 Clamp No. 2U46 9352715006 9352715006 9352715006 9352715006 9352715006 9352715006 –––––
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
OUTDOOR UNIT
Ref.
No.
Description
AOG18ANAKH AOG18ANAK AOG18RNAKH AOG24ANAKH AOG24ANAK AOG24RNAKH AOG30RMADH
Ord.
Q'ty
Part No.
AOG18ANAKH, AOG18ANAK
AOG18RNAKH, AOG24ANAKH
AOG24ANAK, AOG24RNAKH
AOG30RMADH
