OUTDOOR UNIT
2007.04.24 21
31
32
2-Way Valve Assy
33
Coil (Expansion Valve)(A=Red)
34
Coil (Expansion Valve)(B=White)
35
Coil (Expansion Valve)(C=Green)
36
Coil (Expansion Valve)(D=Blue)
3-Way Valve Assy (3/8")
9372205044
9372204054
9900057084
9900057053
9900057060
9900057077
Ref. Description Part number
70
Solenoid 9900165055
71
72
Pipe Thermistor (Red)
Pipe Thermistor (White) 9900322014
9900289010
---
Strainer 9372524015
---
Strainer 9366602019
19 Compressor Assy
20
4-Way Valve Assy
21 Inlet Pipe (Cond) A Assy
22
Outlet Pipe (Cond) A Assy
23
Pressure Switch A Assy
24
Pressure Switch B Assy
25
Accumulator Sub Assy
26
Receiver Tank Sub Assy
27
Valve Plate A Assy
28
Expansion Valve Assy
29
Capillary Assy
30
3-Way Valve Assy (1/2")
9377946010
9374425044
9373461067
9374266067
9367726028
9367727025
9374426072
9373426028
9374628025
9370947106
9372197370
9372205051
Ref. Description Part number
To Next Page
