Model name ASHG18KMTB ASHG22KMTB ASHG24KMTB
Power supply 1Ø 230 V ~50 Hz
Available voltage range 198—264 V
Capacity kW class 5.0 6.0 7.0
Input power W 37.5 47.0 61.6
Running current A 0.35 0.39 0.44
Fan
Airflow rate
Cooling
HIGH
m
3
/h
980 1,060 1,170
MED 810 810 850
LOW 640 640 640
QUIET 510 510 510
Heating
HIGH 1,020 1,060 1,170
MED 850 850 850
LOW 640 640 640
QUIET 510 510 510
Type × Q'ty Cross flow fan × 1
Motor output W 59 59 59
Sound pressure level *
1
Cooling
HIGH
dB (A)
45 48 49
MED 40 40 40
LOW 35 35 35
QUIET 29 29 29
Heating
HIGH 46 48 49
MED 40 40 40
LOW 35 35 35
QUIET 29 29 29
Sound power level
Cooling
dB (A)
60 62 65
Heating 61 62 65
Heat exchanger type
Dimensions (H × W × D) mm
Main1: 210 × 798 × 26.6
Main2: 135 × 798 × 20.0
Sub1: 84 × 798 × 13.3
Sub2: 84 × 798 × 13.3
Fin pitch mm
Main1: 1.2, Main2: 1.1
Sub1: 1.4, Sub2: 1.4
Rows × Stages
Main1: 2 × 10
Main2: 2 × 8
Sub1: 1 × 4
Sub2: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White + Pearl white (painted)
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
mm
280 × 980 × 240
Gross 322 × 1,078 × 346
Weight
Net
kg
12.5
Gross 18
Connection pipe
Size
Liquid
mm (in)
Ø6.35 (Ø1/4)
Gas Ø12.70 (Ø1/2)
Method Flare
Drain hose
Material PP + HDPE
Tip diameter mm Ø13.8 (I.D.), Ø 15.8 to Ø 16.7 (O.D)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type
Wireless remote controller (Option: Wired remote controller, Mobile app*
2
[FGLair
™
])
NOTES:
• The protective function might work when using it outside the operation range.
• *
1
: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *
2
: Available on Google Play
™
store or on App Store
®
. Optional WLAN adapter is also required. For details, refer to the setting manual.
- 17 -
2-5. Wall mounted type
2. Specifications
